[shortdesc] Secure SD-WAN firewall with integrated Wi-Fi 5, powered by SoC4 ASIC, delivering up to 10 / 10 / 6 Gbps firewall throughput and including a 3-Year Enterprise Protection bundle [/shortdesc]
[properties]
| SKU |
FWF-61F-A-BDL-809-36 |
| Form Factor |
Desktop |
| Wireless Standard |
802.11 a/b/g/n/ac-W2 (WiFi 5) |
| Internal Storage |
1x 128 GB SSD |
| Firewall Throughput |
10/10/6 Gbps (1518/512/64 byte UDP packets) |
| Interfaces |
2x GE WAN, 1x GE DMZ, 2x GE FortiLink, 5x GE Internal |
| Dimensions (H x W x L) |
38.5 x 216 x 160 mm (1.5 x 8.5 x 6.3 inches) |
| Weight |
1.01 kg (2.23 lbs) |
| Power Input |
12Vdc, 3A (External Adapter) |
| Bundle Included |
3 Year Enterprise Protection |
[/properties]
[specifications]
| System Performance (Enterprise Traffic Mix) |
| IPS Throughput |
1.4 Gbps |
| NGFW Throughput |
1 Gbps |
| Threat Protection Throughput |
700 Mbps |
| System Performance & Capacity |
| IPv4 Firewall Throughput |
10/10/6 Gbps (1518/512/64 byte UDP packets) |
| Firewall Latency |
3.3 μs |
| Concurrent Sessions (TCP) |
700,000 |
| New Sessions/Second (TCP) |
35,000 |
| Firewall Policies |
2,000 |
| IPsec VPN Throughput |
6.5 Gbps |
| SSL-VPN Throughput |
900 Mbps |
| SSL Inspection Throughput |
630 Mbps |
| Wireless Specifications |
| Radio |
Single Radio (2.4GHz/5GHz) |
| MIMO |
3x3 MU-MIMO |
| Max WiFi Speeds |
1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz |
| Antenna Gain |
3.5 dBi @ 5 GHz, 5 dBi @ 2.4 GHz |
| Hardware Specifications |
| USB Port |
1x USB Port |
| Console Port |
1x RJ45 Console Port |
| Environment & Power |
| Power Consumption (Avg / Max) |
17.5 W / 19.0 W |
| Heat Dissipation |
64.8 BTU/hr |
| Operating Temperature |
32°F to 104°F (0°C to 40°C) |
| Storage Temperature |
-31°F to 158°F (-35°C to 70°C) |
| Humidity |
10% to 90% non-condensing |
| Noise Level |
Fanless 0 dBA |
| Certifications |
| Compliance |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications |
USGv6/IPv6 |
[/specifications]
[accesories]
| Optional Accessories |
Rack Mount Tray (SP-RACKTRAY-02), AC Power Adaptor (SP-FG60E-PDC-5), Wall Mount Kit (SP-FG60F-MOUNT-20) |
[/accesories]
Secure SD-WAN with Storage and Enterprise Protection
The FortiWiFi 61F (FWF-61F-A-BDL-809-36) is an enhanced desktop security appliance designed for businesses that require high performance and local data retention. This 3-Year Enterprise Protection bundle maximizes your security posture with advanced services.
Featuring 128GB of internal SSD storage, the FWF-61F allows for local logging and reporting directly on the device. Powered by the SoC4 ASIC, it delivers up to 10/10/6 Gbps firewall throughput (1518/512/64 byte UDP packets) and integrated 802.11ac-W2 Wi-Fi, all within a silent, fanless form factor.
Key Benefits
-
3-Year Enterprise Protection: Includes FortiGuard security services such as IPS, Anti-Malware Protection (AMP), Web and URL Filtering, Application Control, and AI-powered threat intelligence to protect against known and emerging threats.
-
128GB Onboard SSD: Enables local logging and on-box report storage for improved visibility and compliance support.
-
Powered by SoC4 ASIC: Delivers up to 10/10/6 Gbps firewall throughput (1518/512/64 byte UDP packets) and accelerates SD-WAN application identification.
-
Integrated Wireless: Built-in 802.11ac-W2 Wi-Fi with 3x3 MU-MIMO technology eliminates the need for separate access points.
-
Fanless Operation: Silent 0 dBA design enables deployment in noise-sensitive environments like retail floors and offices.
-
Unified Management: FortiOS consolidates storage, Wi-Fi, and security management into a single console.
Ideal Use Cases
-
Retail & Branch Offices: Perfect for sites needing local log retention for compliance and secure Wi-Fi for operations.
-
Small Businesses: All-in-one networking, security, and storage solution reducing hardware footprint.
-
Highly Regulated Environments: Enterprise Protection bundle meets strict security standards, supported by local data retention capabilities.
Technical Specifications Summary
-
Firewall Throughput (1518/512/64 byte UDP): 10/10/6 Gbps
-
IPS Throughput (Enterprise Mix): 1.4 Gbps
-
NGFW Throughput: 1 Gbps
-
Threat Protection Throughput: 700 Mbps
-
IPsec VPN Throughput (512 byte): 6.5 Gbps
-
SSL-VPN Throughput: 900 Mbps
-
Interfaces: 2x GE RJ45 WAN, 1x GE RJ45 DMZ, 2x GE RJ45 FortiLink (default), 5x GE RJ45 internal
-
Wireless: Single Radio (2.4GHz/5GHz) 802.11 a/b/g/n/ac-W2; 3x3 MU-MIMO; 1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz
-
Internal Storage: 1x 128 GB SSD
-
Power / Noise: 12Vdc, 3A; Fanless 0 dBA (avg/max power consumption 17.5 W / 19.0 W)
Upgrade Your Network Security
Protect your business with the storage-optimized FortiWiFi 61F and 3-Year Enterprise Protection bundle today.
