| Image Sensor Details |
1/2.8" progressive scan RGB CMOS; pixel size 2.90 µm; signal-to-noise ratio >55 dB |
| Lens Details |
Varifocal 3.2–7.2 mm, F1.6–2.7, fixed iris, IR corrected, remote zoom and focus; minimum focus distance 1.0 m (3.2 ft) |
| Camera Adjustment |
Pan ±180°; tilt −10° to +65°; rotation ±180° |
| Shutter Speed |
1/20000 s to 1.5 s |
| Minimum Illumination Values |
Color: 0.12 lux at 50 IRE, F1.6; B/W: 0.03 lux at 50 IRE, F1.6; 0 lux with IR illumination on |
| Video Resolutions (16:9) |
1920×1080, 1280×720, 640×360 |
| Video Resolutions (4:3) |
1280×960, 640×480, 320×240 |
| Frame Rate |
Up to 25/30 fps (50/60 Hz) in all supported resolutions |
| IR Illumination Specs |
OptimizedIR with 850 nm LEDs; range 20 m (66 ft) or more depending on scene |
| DORI Distances (wide–tele) |
Detect: 43.7–101.8 m; Observe: 17.4–40.4 m; Recognize: 8.8–20.4 m; Identify: 4.4–10.2 m |
| Image Processing |
Axis Zipstream for H.264/H.265, Forensic WDR, Lightfinder 2.0, OptimizedIR, digital PTZ, rotation 0°/90°/180°/270° including corridor format, privacy masks, text and image overlay |
| Video Streaming |
Up to 20 unique and configurable streams; controllable frame rate and bandwidth; VBR/ABR/MBR; low latency mode; video streaming indicator |
| System on Chip |
ARTPEC-8 with deep learning processing unit (DLPU) |
| Memory |
1 GB RAM; 8 GB Flash |
| AXIS Object Analytics |
Detects and classifies humans and vehicles (cars, buses, trucks, bikes, other); scenarios include line crossing, object in area, time in area, crossline counting, occupancy in area, tailgating detection, PPE monitoring (beta), motion in area and motion line crossing |
| AXIS Audio Analytics |
Sound pressure level, adaptive audio detection and classification of scream, shout, glass break and speech; generates event metadata on detections |
| AXIS Image Health Analytics |
Monitors for blocked or redirected image, blurred image and underexposed image with configurable sensitivity and validation period |
| AXIS Scene Metadata |
Metadata for humans, faces, vehicles (cars, buses, trucks, bikes) and license plates; attributes include vehicle color, upper/lower clothing color, confidence and position; audio level metadata |
| Event Triggers |
Device status, temperature conditions, IP change, network lost, system ready, live stream active, edge storage status, manual or virtual inputs, MQTT, schedules, day/night mode, tampering, bitrate degradation and motion-related events |
| Event Actions |
Image upload via FTP/HTTP/HTTPS/SFTP/network share/email; video recording; overlay text; SNMP traps; MQTT publish; notifications; day/night and IR control; status LED control; security actions including erase configuration |
| Edge Security Features |
Axis Edge Vault with secure keystore (CC EAL 6+, FIPS 140-3 Level 3), signed OS, secure boot, encrypted filesystem (AES-XTS-Plain64 256-bit), Axis device ID and signed video |
| Network Security |
IEEE 802.1X (EAP-TLS, PEAP-MSCHAPv2), IEEE 802.1AR, HTTPS/HSTS, TLS v1.2/v1.3, Network Time Security (NTS), X.509 certificates, host-based firewall |
| Standards & Certifications |
UL/cUL, UKCA, CE, EAC, VCCI, RCM, BSMI; EMC CISPR 32/35 Class A, EN 55032 Class A, EN 55035, EN 61000-6-1/6-2; IEC/EN 60529 IP66, IEC/EN 62262 IK10, NEMA 250 Type 4X; ETSI EN 303 645; NIST SP500-267; TAA compliant |
| Operating Environment |
−30 °C to 50 °C (−22 °F to 122 °F), 10–100% RH condensing; maximum temperature according to NEMA TS 2 (2.2.7) 74 °C (165 °F) |
| Storage Environment |
−40 °C to 65 °C (−40 °F to 149 °F), 5–95% RH non-condensing |
| Storage Options |
microSD/microSDHC/microSDXC with AES-XTS-Plain64 256-bit encryption; network-attached storage (NAS) |
| Supported Languages |
Czech, Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Simplified Chinese, Spanish, Swedish, Thai, Traditional Chinese, Turkish, Vietnamese |
