Description
The Omron ZX-GTC41 is a high-precision sensor amplifier controller designed for use with Omron’s ZX-GT series displacement and measurement sensors. It provides built-in RS-232C communication for fast data exchange and control, enabling accurate position and dimension measurement in industrial automation and inspection applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Sensors |
| Part Number |
ZX-GTC41 |
| Subcategory |
Sensor Amplifier Controller |
| Series |
ZX-GT Series |
| Type |
Amplifier/Controller Unit |
| Compatible Sensors |
ZX-GT Displacement Sensors |
| Communication Interface |
RS-232C Built-In |
| Input/Output Type |
PNP |
| Connection Type |
Standard Omron 103086 connector |
| PLC Compatibility |
Fully compatible with Omron PLCs and systems |
| Signal Processing |
Digital amplifier with precision filtering |
| Power Supply |
24 VDC nominal |
| Housing Material |
Industrial-grade resin |
| Shield Type |
Positive-Negative-Positive (PNP) configuration |
| Mounting Style |
DIN rail or panel mount |
| Operating Temperature |
0°C to +50°C |
| Storage Temperature |
–20°C to +65°C |
| Application |
Displacement and dimension measurement control |
| Compliance |
CE, RoHS |
| Weight |
Approx. 200 g |
Information About ZX-GTC41
The ZX-GTC41 belongs to Omron’s ZX-GT series, a family of modular sensor systems engineered for high-resolution measurement and process control. This controller serves as the amplifier interface, providing advanced signal processing, calibration, and communication functions for connected laser or displacement sensors. It supports PNP input/output configuration and integrates easily with PLCs or PC-based control systems through RS-232C communication. Designed for precision measurement and data monitoring, the ZX-GTC41 ensures reliable and repeatable operation in applications requiring micrometer-level accuracy, such as thickness measurement, alignment, or part inspection.
Key Features:
- Integrated RS-232C Communication: Allows fast serial data transfer and remote parameter control.
- Sensor Compatibility: Designed for use with ZX-GT series sensors for precision measurement applications.
- PNP I/O Configuration: Provides easy integration with Omron PLCs and control networks.
- High-Accuracy Signal Processing: Ensures stable readings for displacement and dimension detection.
- Compact Modular Design: Fits neatly in control panels or machine enclosures.
- Robust Construction: Industrial-grade build designed for long-term reliability in automation environments.
- Flexible Application: Suitable for in-line inspection, dimensional gauging, and process monitoring.
- User-Friendly Setup: Features simple wiring and intuitive operation for rapid deployment.
The ZX-GTC41 delivers the reliability and precision required for high-performance sensor measurement and industrial data control systems.
