Description
The RRD-PRO-WH is a Maestro PRO LED+ RF dimmer engineered for Lutron RadioRA 2 and RA3 lighting systems. It delivers smooth, customizable dimming of LED and traditional lighting loads with fade-on and fade-off functionality. Neutral-optional wiring and screw terminals enable fast installation as a retrofit or upgrade solution.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Lutron |
| Category |
|
| Part Number |
RRD-PRO-WH |
| Subcategory |
RF Dimmers |
| System Compatibility |
RadioRA 2, RA2 Select, RA3 |
| Load Types |
LED, ELV, MLV, incandescent, halogen |
| LED Load Rating |
250 W |
| Incandescent/Halogen Rating |
500 W |
| MLV Rating |
400 VA
|
| Wiring |
Screw terminals, neutral optional |
| Installation |
Single-pole or multi-location (with companion dimmers) |
| Wireless Communication |
RF Maestro technology |
| Fade-on/Fade-off |
Adjustable |
| Finish Color |
White (WH) |
| Dimensions |
Standard decorator-style wallbox size |
| Weight |
0.18 kg (approx.) |
Information About RRD-PRO-WH
The RRD-PRO-WH replaces standard wall switches to provide wireless dimming control via Maestro RF technology. Featuring PRO LED+ advanced dimming, it supports LED loads up to 250 W and incandescent/halogen loads up to 500 W. It integrates with keypads, Pico remotes, occupancy sensors and system apps in RadioRA networks for whole-home control. Suitable for modern interiors, the sleek white device operates in single-pole or multi-location configurations with companion dimmers.
Key Features:
- PRO LED+ Technology: Provides advanced dimming for a wide range of LED, ELV, MLV, incandescent and halogen bulbs.
- Neutral Optional Wiring: Flexible installation in existing switch boxes without the need for a neutral conductor.
- Custom Fade Rates: Lights gradually brighten and dim for a premium user experience.
- Wireless RF Control: Communicates with RadioRA 2/3 systems, Pico remotes, sensors and mobile app.
- High Load Capacity: Supports up to 250 W LED, 500 W incandescent/halogen, 400 VA MLV loads.
- Multi-location Dimming: Supports up to nine companion dimmers for control from multiple locations.
The RRD-PRO-WH delivers the reliability and precision required for modern smart lighting control applications.
