Overview
Gigabyte G4L4-SD1-LAX5 is a 4U rackmount GPU server featuring dual Intel Xeon 6 6700/6500 series processors and up to 8 TB DDR5 memory across 32 DIMM slots. It includes Nvidia HGX B200 with 8 SXM GPUs, 8 Gen5 NVMe drives, PCIe Gen5 expansion, and advanced management protocols for high-performance AI and HPC workloads.
Specifications
Model Number: G4L4-SD1-LAX5
Brand: Gigabyte
Alt Part Number(s): G4L4-SD1-LAX5
Product Type: GPU Server
Technical Description
Brand: Gigabyte
Model Number: G4L4-SD1-LAX5
Processor Type:Dual Intel Xeon 6 6700/6500 Series
Processor Socket: 2 x LGA 4710 Socket E2
Number of Channels: 8-Channel
Memory Supported: 8TB
Memory Technology: DDR5
RDIMM: Up to 6400 MT/s (1DPC), 5200 MT/s (2DPC)
MRDIMM: Up to 8000 MT/s
Memory Slots: 32 x DIMM
Storage Type: 8 x 2.5" Gen5 NVMe
Modular GPU: NVIDIA HGX B200 with 8 x SXM GPUs
Expansion Slots: 16
Chipset Type: System on Chip
Power Supply: 4+4 3000W 80 Plus
Motherboard: MSB4-PE0
Controller Type: PCIe Gen5x4
Graphics Controller: Aspeed AST2600
Output Voltage: 208 - 230 V AC
Protocols: Web, SNMP, Telnet
Form Factor: 4U Rackmount/GPU server
*
