Description
he Omron E3S-VS1B4 is a definite-reflective photoelectric sensor designed for precise short-range detection up to 12 mm. Operating on DC power with a 3-wire PNP output configuration, it provides stable switching performance for industrial automation systems. The horizontal mounting style and integrated 2 meter cable allow straightforward installation in compact machine applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Sensors |
| Part Number |
E3S-VS1B4 |
| Subcategory |
Definite-Reflective Photoelectric Sensors |
| Sensing Method |
Definite-Reflective |
| Sensing Distance |
12 mm |
| Output Type |
PNP Transistor |
| Wiring Configuration |
3-Wire DC |
| Supply Voltage |
10–30 VDC (Typical for Series) |
| Mounting Orientation |
Horizontal |
| Connection Type |
2 m Pre-Wired Cable |
| Application |
Precision Part Detection and Automation |
| Weight |
Approx. 0.2 kg |
Information About E3S-VS1B4
The E3S-VS1B4 belongs to Omron’s E3S series of industrial photoelectric sensors engineered for reliable object detection in manufacturing environments. Utilizing definite-reflective sensing technology, it detects objects within a fixed short sensing distance without requiring a separate reflector. The sensor operates on DC supply voltage and features a PNP transistor output compatible with sourcing PLC inputs. Built for panel or bracket mounting, it is suited for precision positioning, part detection, and small component sensing tasks.
Key Features:
- 12 mm Sensing Distance: Designed for precise short-range object detection.
- Definite-Reflective Technology: Provides fixed-distance detection without external reflectors.
- PNP Output Configuration: Suitable for sourcing input PLC systems.
- 3-Wire DC Operation: Supports standard industrial DC wiring configurations.
- Horizontal Mounting Style: Enables flexible installation in compact machinery.
- 2 Meter Pre-Wired Cable: Simplifies connection and reduces installation time.
- Industrial-Grade Housing: Built for durability in automation environments.
The E3S-VS1B4 delivers the reliability and precision required for short-range industrial photoelectric sensing applications.
