Overview
ASUS ESC8000A-E12-26WOCP from the 4U GPU server series features dual AMD EPYC 9004 64-Core processors with 24 DDR5 DIMM slots supporting up to 3 TB memory. It includes 8 PCIe Gen5 GPU slots, 8 hot-swap NVMe/SATA/SAS bays, and up to 4 × 3000 W redundant power supplies for high-performance AI and HPC workloads.
Specifications
Model Number:ESC8000A-E12-26WOCP
Brand:ASUS
Alt Part Number(s):ESC8000A-E12-26WOCP
Product Type: Server
Technical Description
Brand:ASUS
Model:ESC8000A-E12-26WOCP
Form Factor: 4U rackmount, GPU Server
Processor: 2 × AMD EPYC 9004 (Socket SP5)
Maximum CPU TDP: ~400 W per CPU
Memory Slots: 24 DDR5 DIMM slots
Maximum Memory: ~3 TB
Memory Speed: DDR5-4800+
GPU Slots: 8 dual-slot PCIe Gen5
Storage Bays: 8 hot-swap 3.5"/2.5" (NVMe/SATA/SAS)
PCIe Expansion Slots: 11 PCIe Gen5
NVMe Support: Backplane + PCIe lanes
Power Supply: Up to 4 × 3000 W redundant (80 PLUS Titanium)
Cooling: Dedicated CPU + GPU airflow tunnels
Management: ASMB11-iKVM BMC (remote management)
Use Case: AI; HPC; GPU compute; virtualization
*
