Description

The Omron STC-HD213DV is a high-definition industrial camera designed for precision imaging and inspection applications. It features a 2.0 MP CMOS sensor with 1920 × 1080 resolution and supports up to 60 fps for real-time image capture. This camera is used in automation systems requiring accurate visual monitoring and analysis.



Technical Specifications

Condition	New/Never Used Surplus
Brand	Omron
Category	Business & Industrial
Part Number	STC-HD213DV
Subcategory	Industrial Cameras
Series	HD213
Camera Type	Color
Resolution	1920 × 1080
Megapixels	2.0 MP
Frame Rate	60 fps
Sensor Type	CMOS (1/2.8")
Pixel Size	2.8 µm
Shutter Type	Global
Interface	DVI (HDMI compatible)
Lens Mount	C-Mount
Supply Voltage	9–15 VDC
Operating Temperature	0°C to 48°C
Dimensions	40 × 40 × 48.9 mm
Weight	129 g

Information About STC-HD213DV

The STC-HD213DV is part of Omron’s industrial imaging solutions (Sentech series), developed for machine vision and inspection tasks. It utilizes a 1/2.8" CMOS sensor with global shutter capability to ensure consistent image capture in dynamic environments. The camera supports DVI output over HDMI, allowing direct connection to monitors without the need for a PC. Its compact cased design with C-mount compatibility enables integration with a wide range of industrial lenses and vision systems.

Key Features:

• 2.0 MP resolution: Provides Full HD 1920 × 1080 image quality for detailed inspection.
• High frame rate: Supports up to 60 fps for real-time imaging applications.
• CMOS image sensor: Ensures efficient image capture with stable performance.
• DVI/HDMI output: Allows direct connection to display devices without additional hardware.
• Global shutter operation: Reduces motion distortion in high-speed environments.
• C-mount lens compatibility: Supports a wide range of industrial lenses.
• Compact industrial design: Enables installation in space-constrained systems.
• Wide operating voltage range: Operates from 9 to 15 VDC for flexible integration.

The STC-HD213DV delivers the reliability and precision required for industrial imaging and machine vision applications.
