Description
The ES100X-AAWHFB is a versatile digital process controller from Omron’s ES100X Series that delivers advanced control and monitoring functionality for temperature and process applications. It features hybrid PID and fuzzy-logic control, supports dual analog inputs, and offers RS-232C/RS-422/485 communications for integration with automation systems. Designed for high precision and flexible configuration, this controller enables optimized process regulation in demanding industrial environments.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Industrial Automation and Controls |
| Part Number |
ES100X-AAWHFB |
| Subcategory |
Digital Process Controllers |
| Series |
ES100X Series |
| Type |
Digital Process Controller |
| Supply Voltage |
100-240 VAC, 50/60 Hz |
| Analog Inputs |
2 channels (4-20 mA or 1-5 V) |
| Digital I/O Options |
Configurations include internal 3 inputs / optional 8-input expansion |
| Communication |
RS-232C and/or RS-422/485 (depending on model suffix) |
| Control Methods |
Advanced PID + Fuzzy Logic, Cascade, Ratio, Feed Forward |
| Rated Ambient Temperature |
0 °C to +50/55 °C (typical) |
| Panel Cutout Dimensions |
Standard 96 × 96 mm (varies by panel version) |
| Outputs |
Two built-in control outputs, output module required for full configuration |
| Programming Interface |
Front-panel keypad, PC software support |
| Protection Rating |
Panel mount (front) standard IP rating where applicable |
| Compliance |
CE, UL Listed, RoHS Compliant |
| Weight |
Approx. 1.1 kg (2.4 lb) |
Information About ES100X-AAWHFB
The ES100X-AAWHFB belongs to Omron’s ES100X family of intelligent digital controllers engineered to combine analog and digital processing with program control and network communication. It supports two analog input channels (4-20 mA or 1-5 V), built-in communications (RS-232C/RS-422/485), and a high-resolution 4-digit display with user-assignable function keys. The unit accepts a 100-240 VAC wide-range supply and is programmable via front panel or PC software, making it suitable for applications requiring cascade control, ramp/soak profiles, or multi-step logic.
Key Features:
- Hybrid PID + Fuzzy Logic Control: Enables refined regulation of process variables with minimal overshoot.
- Dual Analog Inputs: Two channels support 4-20 mA or 1-5 V signals for flexible sensor interface.
- Built-in Communications: RS-232C/RS-422/485 interface supports remote monitoring and configuration.
- Wide Supply Range: Accepts 100-240 VAC, 50/60 Hz for ease of global deployment.
- Modular Output Capability: Output modules can be added for relays, SSR drives, or linear outputs.
- Programmable Function Keys: Front panel keys can be assigned to frequently used parameters for quick access.
- Front Panel Interface: Clear display and intuitive menus simplify setup and operation.
- Flexible Logic & Profile Control: Supports ramp/soak, feed-forward, cascade control and up to 400 steps or 99 program patterns.
The ES100X-AAWHFB delivers the reliability and precision required for high-performance process control in industrial automation systems.
