The R283-ZK0-ACL1 (also referred to by the part number 6NR283ZK0DR000ACL1) is a high-performance 2U Rack Server from GIGABYTE. It is designed for demanding data centre applications, including high-density computing and hybrid cloud environments.
Specifications
Model Number: R283-ZK0-ACL1
Brand: Gigabyte
Alt Part Number(s): R283-ZK0-ACL1
Product Type: Barebone Server
Technical Description
Brand: Gigabyte
Model Number: R283-ZK0-ACL1
Processor Type: AMD EPYC 9004/ 9005 series
Processor Core: 256 Core/512 Thread
Processor Power: up to 500W per CPU
Processor Socket: Dual Socket SP5 (LGA 6096)
Motherboard: MZK3-LM0
Chipset Type: System on Chip
Graphics Controller: ASPEED AST2600
Networking: 2 × 1GbE (Intel I350-AM2)
Number of Drive Bays: 8 × 2.5" hot-swap (Gen5 NVMe), 4 × 2.5" SATA / SAS,Up to 3 × M.2 (PCIe Gen3 x4/x2)
Expansion Slots: 4 × PCIe Gen5 x16 FHHL, 2 × OCP NIC 3.0 (PCIe Gen5 x16)
Memory Supported: 12TB, 24TB
Memory Size: ( 512 GB DIMMs), 3DS RDIMM: (up to 256 GB) per Moduls
Memory Technology: DDR5 RDIMM
Memory Speed: Up to 5200 MT/s, Up to 4800 MT/s
Memory Slots: 48 × DIMM
Memory Channels: 12-channel per CPU
Power Supply: 1+1 redundant 2700W 80 PLUS Titanium
System Cooling: 4 × 80mm hot-swappable fans
Form Factor: 2U Rackmount
