Description
The Omron C200HE-CPU42-E is a programmable CPU unit from the C200H series with a 7.2K-word program capacity and support for up to 880 I/O points. It uses stored program control and supports ladder diagram programming for industrial automation tasks.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
PLC & PAC Control Systems |
| Part Number |
C200HE-CPU42-E |
| Subcategory |
CPU Modules |
| Series |
C200H |
| Program Capacity |
7.2K words max |
| Memory |
6K words |
| Control Method |
Stored program |
| Instruction Length |
1 to 4 words/instruction |
| LED Indicators |
Yes |
| Clock Functions |
Yes |
| I/O Points Supported |
Up to 880 |
| RS-232C |
Yes |
| Special Instructions |
231 |
| High-Density I/O Units |
10 units + 5 x 64-point units |
| Expansion Rack Support |
2 racks max |
| Programming Method |
Ladder diagram |
| Device Type |
CPU Unit |
| Weight |
13 lbs (5.9 kg) |
Information About C200HE-CPU42-E
The C200HE-CPU42-E is a CPU module within the Omron C200H family, designed for integration in modular PLC architectures. It features a 7.2K-word user program memory and supports high-density I/O configurations, including up to 10 standard units and five 64-point units. With built-in RS-232C communication, LED indicators, clock functions, and 231 special instructions, it offers a flexible and comprehensive platform for complex automation routines. It supports two expansion racks and is engineered for ladder diagram programming to streamline deployment in factory and process automation.
Key Features:
-
7.2K Word Program Capacity: Supports large-scale control routines with space for extensive logic and user-defined instructions.
-
Stored Program Control Method: Executes sequences from internal memory, improving cycle speed and operational consistency.
-
High-Density I/O Compatibility: Connects up to 10 standard and 5 64-point I/O units, enabling broad system expansion.
-
RS-232C Communication Port: Provides serial connectivity for programming, diagnostics, or interfacing with external equipment.
-
231 Special Instructions: Includes advanced instruction set for handling timers, counters, data processing, and control tasks.
-
Built-In LED Indicators and Clock: Offers real-time monitoring and scheduling capabilities for improved control visibility.
-
Ladder Diagram Programming Support: Simplifies configuration with graphical logic representation common in industrial control.
-
Expansion Rack Capacity: Accommodates up to two expansion racks for scalable deployment across control panels.
The C200HE-CPU42-E delivers the reliability and precision required for modular, mid-range industrial control systems in manufacturing and process automation.
