Description
The Allen-Bradley 100-C60D00 is a 60 A IEC contactor from the Bulletin 100-C series, designed for controlling electric motors and other loads.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Allen-Bradley
|
| Category |
Contactors & Starters
|
| Part Number |
100-C60D00 |
| Subcatecory |
|
|
|
110-120 VAC |
Frequency
|
50/60 HZ |
| Coil Termination |
Line Side |
| Terminal Type |
Screw |
| Poles |
3 Normally Open |
| Current Rating |
60 AMP |
| Mounting Style |
DIN Rail / Base Mount |
| Weight |
3.15 lbs |
Information About 100-C60D00
The Allen-Bradley 100-C60D00 is a compact IEC motor contactor designed for reliable control of motors and electrical loads in industrial automation systems. Engineered for durability and flexibility, it supports high-performance switching in demanding applications while optimizing space in control panels.
Key Features:
- Type: IEC Motor Contactor
- Series: Allen-Bradley Bulletin 100-C Series
- Rated Current (AC-3): 60 A @ 400V
- Motor Rating: Up to 30 kW (40 HP) @ 400/415V
- Number of Poles: 3 (3 Normally Open contacts)
- Auxiliary Contacts: Not included (optional add-on)
- Coil Voltage: 110–120V AC, 50/60 Hz
- Control Circuit Type: AC coil
- Mechanical Life: Up to 10 million operations
- Electrical Life: Up to 1 million operations (AC-3 duty)
- Mounting Options: DIN rail or panel mounting
- Terminal Type: Screw terminals
- Housing Material: Thermoplastic, industrial-grade
- Ingress Protection: IP20 (when mounted inside a panel or enclosure)
- Standards Compliance: CE, UL, CSA, CCC certified
- Operating Temperature Range: -25 °C to +60 °C (-13 °F to +140 °F)
The Allen-Bradley 100-C60D00 offers a rugged and efficient motor control solution with long operational life and flexible mounting. Its compact design and global compliance make it a dependable choice for a wide range of control panel applications.
