[shortdesc] Secure SD-WAN firewall with integrated Wi-Fi 6 (802.11ax) and 2x GE SFP/RJ45 shared media ports, powered by SP4 ASIC, delivering up to 10/10/7 Gbps firewall throughput for flexible branch connectivity [/shortdesc]
[properties]
| SKU |
FWF-80F-2R-A |
| Form Factor |
Desktop/Wall Mount/Rack Tray |
| Wireless Standard |
802.11a/b/g/n/ac/ax (Wi-Fi 6) |
| Firewall Throughput |
10/10/7 Gbps (1518/512/64 byte UDP) |
| Interfaces |
2x GE RJ45/SFP Shared Media Pairs, 6x GE RJ45 Internal Ports, 2x GE RJ45 FortiLink Ports (Default) |
| Dimensions (H x W x L) |
60 x 216 x 178 mm (2.4 x 8.5 x 7.0 inches) |
| Weight |
1.5 kg (3.3 lbs) |
| Power Input |
12V DC, 5A (dual redundancy optional) |
[/properties]
[specifications]
| System Performance (Enterprise Traffic Mix) |
| IPS Throughput |
1.4 Gbps |
| NGFW Throughput |
1 Gbps |
| Threat Protection Throughput |
900 Mbps |
| System Performance & Capacity |
| Firewall Latency |
3.23 μs |
| Concurrent Sessions (TCP) |
1.5 Million |
| New Sessions/Second (TCP) |
45,000 |
| Firewall Policies |
5,000 |
| IPsec VPN Throughput |
6.5 Gbps |
| SSL-VPN Throughput |
950 Mbps |
| SSL Inspection Throughput |
715 Mbps |
| Wireless Specifications |
| Radio |
Dual WiFi Radio (5 GHz, 2.4 GHz) 802.11a/b/g/n/ac/ax + 1 Scanning Radio |
| MU-MIMO |
2x2 |
| Max WiFi Speeds |
574 Mbps @ 2.4 GHz, 1201 Mbps @ 5 GHz |
| Antenna Ports |
3x SMA (External) |
| Hardware Specifications |
| GE RJ45/SFP Shared Media Pairs |
2 |
| GE RJ45 Internal Ports |
6 |
| GE RJ45 FortiLink Ports (Default) |
2 |
| USB Ports |
1 |
| Console Port |
1 |
| Trusted Platform Module (TPM) |
Yes |
| Environment & Power |
| Power Consumption (Avg / Max) |
22.9 W / 27.9 W |
| Heat Dissipation |
95.26 BTU/h |
| Operating Temperature |
32°F to 104°F (0°C to 40°C) |
| Storage Temperature |
-31°F to 158°F (-35°C to 70°C) |
| Humidity |
10% to 90% non-condensing |
| Noise Level |
24.14 dBA |
| Certifications |
| Compliance |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications |
USGv6/IPv6 |
[/specifications]
[accesories]
| Optional Accessories |
Rack Mount Tray (SP-RACKTRAY-02), Wall Mount Kit (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FWF80F-PDC-5), 1 GE SFP RJ45 Transceiver Module (FN-TRAN-GC), 1 GE SFP SX Transceiver Module (FN-TRAN-SX), 1 GE SFP LX Transceiver Module (FN-TRAN-LX), 1GE SFP Transceiver 90km Range (FR-TRAN-ZX) |
[/accesories]
Integrated SFP, Wi-Fi 6, and Secure SD-WAN for Branch Offices
The FortiWiFi 80F-2R (FWF-80F-2R-A) is a high-performance desktop firewall designed for modern branch environments that require flexible connectivity and integrated wireless. Powered by the Fortinet SP4 ASIC, it delivers consistent firewall performance while combining wired, fiber-ready, and Wi-Fi 6 networking in a compact form factor.
With 2x GE RJ45/SFP shared media pairs, the FortiWiFi 80F-2R supports both copper and fiber uplinks, enabling adaptable WAN and LAN deployment options. Integrated dual-band Wi-Fi 6 with a dedicated scanning radio provides reliable wireless access while supporting secure network operations across distributed sites.
Key Benefits
-
Flexible SFP Connectivity: Two GE RJ45/SFP shared media pairs support copper or fiber connections for adaptable network design.
-
Integrated Wi-Fi 6: Dual-band 802.11ax wireless with an additional scanning radio delivers high-speed and resilient wireless access.
-
Powered by SP4 ASIC: Hardware acceleration enables consistent firewall and SD-WAN performance for branch deployments.
-
SD-Branch Ready: Includes two GE RJ45 FortiLink ports (default) to extend network connectivity to access-layer devices.
-
Compact Deployment Options: Desktop, wall-mount, or rack-tray installation flexibility for space-constrained environments.
-
Hardware-Based Security: Integrated Trusted Platform Module (TPM) enhances device integrity and cryptographic protection.
Ideal Use Cases
-
Branch Offices: Consolidates wired, fiber, and wireless connectivity into a single edge device.
-
Retail Locations: Supports flexible WAN options and reliable Wi-Fi connectivity for distributed sites.
-
Small to Medium Businesses: Enterprise-grade firewall hardware with integrated Wi-Fi 6 in a compact form factor.
Technical Specifications Summary
-
Firewall Throughput (UDP): 10/10/7 Gbps (1518/512/64 byte)
-
IPS Throughput: 1.4 Gbps
-
NGFW Throughput: 1 Gbps
-
Threat Protection Throughput: 900 Mbps
-
IPsec VPN Throughput (512 byte): 6.5 Gbps
-
SSL-VPN Throughput: 950 Mbps
-
Wireless: Dual Wi-Fi radio (2.4 GHz and 5 GHz) with 802.11a/b/g/n/ac/ax support plus a dedicated scanning radio
-
Interfaces: 2x GE RJ45/SFP shared media pairs, 6x GE RJ45 internal ports, 2x GE RJ45 FortiLink ports (default)
-
Physical: 60 x 216 x 178 mm, 1.5 kg
Upgrade Your Network Infrastructure
Deploy flexible wired and wireless connectivity at the network edge with the FortiWiFi 80F-2R.
