[shortdesc] Secure SD-WAN firewall with integrated 802.11ac Wi-Fi, fanless desktop form factor, 5 Gbps firewall throughput, up to 600 Mbps threat protection, including 3-year FortiGuard Enterprise Protection bundle [/shortdesc]
[properties]
| SKU |
FWF-40F-A-BDL-809-36 |
| Form Factor |
Desktop (Fanless) |
| Wireless Standard |
802.11 a/b/g/n/ac-W2 (MIMO 3x3) |
| Firewall Throughput |
5 Gbps (1518/512/64 byte UDP) |
| Interfaces |
5x GE RJ45 ports (1x GE WAN/DMZ, 4x GE Internal incl. 1x FortiLink) |
| Dimensions (H x W x L) |
40.5 x 216 x 160 mm (1.6 x 8.5 x 6.3 inches) |
| Weight |
1 kg (2.2 lbs) |
| Power Input |
12Vdc, 3A (External Adapter) |
| Bundle Included |
3 Year Enterprise Protection (IPS, AMP, Web Filtering, OT Security, and more) |
[/properties]
[specifications]
| System Performance (Enterprise Traffic Mix) |
| IPS Throughput |
1 Gbps |
| NGFW Throughput |
800 Mbps |
| Threat Protection Throughput |
600 Mbps |
| System Performance & Capacity |
| Firewall Latency |
2.97 μs |
| Concurrent Sessions (TCP) |
700,000 |
| New Sessions/Second (TCP) |
35,000 |
| Firewall Policies |
2,000 |
| IPsec VPN Throughput |
4.4 Gbps |
| SSL-VPN Throughput |
490 Mbps (SSL VPN not supported on FortiOS 7.6.0 and above) |
| Wireless Specifications |
| Radio |
Single Radio (2.4GHz/5GHz) |
| Max WiFi Speeds |
1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz |
| Antennas |
3 x SMA antenna ports (Antenna gain: 3.5 dBi @ 5 GHz, 5 dBi @ 2.4 GHz) |
| Hardware Specifications |
| USB Port |
1x USB Port |
| Console Port |
1x RJ45 Console Port |
| Environment & Power |
| Power Consumption (Avg / Max) |
14.6 W / 16.6 W |
| Heat Dissipation |
56.64 BTU/h |
| Operating Temperature |
32°F to 104°F (0°C to 40°C) |
| Storage Temperature |
-31°F to 158°F (-35°C to 70°C) |
| Humidity |
10% to 90% non-condensing |
| Noise Level |
Fanless 0 dBA |
| Certifications |
| Compliance |
FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB |
| Certifications |
USGv6/IPv6 |
[/specifications]
[accesories]
| Optional Accessories |
Rack Mount Tray (SP-RACKTRAY-02), Wall Mount Kits (SP-FG60F-MOUNT-20), AC Power Adaptor (SP-FG-40F-PA-10(-XX)) |
[/accesories]
Unified Security and Wireless Connectivity
The FortiWiFi 40F (FWF-40F-A) delivers a converged networking and security solution designed for small businesses and branch offices. Powered by Fortinet's patented SoC4 SD-WAN ASIC, it integrates Next-Generation Firewall (NGFW) capabilities with dual-band 802.11ac wireless. This 3-Year Enterprise Protection bundle ensures your network is defended against known, unknown, and zero-day threats through AI-powered security services.
With its fanless, compact desktop design, the FortiWiFi 40F operates silently, making it ideal for noise-sensitive environments like retail stores or home offices. The integrated Wi-Fi eliminates the need for separate access points, reducing hardware clutter while maintaining unified management through FortiOS.
Key Benefits
-
Comprehensive Enterprise Protection: Includes a 3-Year subscription for IPS, Anti-Malware, URL Filtering, OT Security, and more.
-
Integrated Wireless: Features built-in 802.11ac-W2 Wi-Fi with 3x3 MIMO technology for reliable, high-speed wireless connectivity.
-
High-Performance ASIC: The SoC4 processor delivers 5 Gbps firewall throughput and accelerates SD-WAN application identification.
-
Fanless Design: Operates silently (0 dBA), ensuring suitability for desktop use in open office environments.
-
Unified Management: FortiOS provides a single pane of glass for managing both wired and wireless networking alongside advanced security policies.
-
Secure SD-WAN: Delivers application-aware steering and fast IPsec VPN performance for efficient cloud access.
Ideal Use Cases
-
Retail & Branch Offices: Unified security and Wi-Fi for point-of-sale systems and customer guest access in a single device.
-
Small Business: Enterprise-grade threat protection without the complexity of managing multiple appliances.
-
Remote Work: Secure connectivity for home offices requiring reliable VPN and wireless performance.
Technical Specifications Summary
-
IPv4 Firewall Throughput: 5 Gbps (1518/512/64 byte UDP)
-
IPS Throughput (Enterprise Mix): 1 Gbps
-
NGFW Throughput: 800 Mbps
-
Threat Protection Throughput: 600 Mbps
-
IPsec VPN Throughput (512 byte): 4.4 Gbps
-
SSL-VPN Throughput: 490 Mbps (SSL VPN not supported on FortiOS 7.6.0 and above)
-
Wi-Fi Performance: 1300 Mbps @ 5 GHz, 450 Mbps @ 2.4 GHz; Single Radio (2.4GHz/5GHz)
-
Sessions: 700,000 concurrent TCP sessions; 35,000 new sessions/second
-
Power & Acoustics: 12Vdc, 3A input; 14.6 W avg / 16.6 W max; Fanless 0 dBA
-
Physical: 40.5 x 216 x 160 mm; 1 kg (2.2 lbs)
-
Environment & Compliance: 0°C to 40°C operating; FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB; USGv6/IPv6
Upgrade Your Network Security
Secure your branch or small business with the FortiWiFi 40F and 3-Year Enterprise Protection bundle today.
