Description
The Copeland ZF09K4E-TFD-961 is a hermetic scroll compressor designed for low-temperature refrigeration applications requiring stable and efficient performance. It supports multi-refrigerant operation and three-phase power, delivering reliable capacity with low noise and vibration characteristics.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Copeland |
| Category |
HVAC |
| Part Number |
ZF09K4E-TFD-961 |
| Subcategory |
Scroll Compressors |
| Compressor Type |
Hermetic Scroll |
| Application |
Low Temperature Refrigeration |
| Cooling Capacity @ -10°F Evap |
10,700 BTU/h |
| Nominal Capacity |
~9,000–10,700 BTU |
| Horsepower |
3 HP |
| Refrigerant Compatibility |
Multi-Refrigerant (Including R22) |
| Voltage Rating |
380–420 VAC / 460 VAC |
| Frequency |
50 / 60 Hz |
| Phase |
Three Phase |
| Motor Protection |
Internal Overload |
| Liquid Injection |
Yes |
| Crankcase Heater (CCH) |
Yes |
| Discharge Connection |
1 in Rotolock |
| Suction Connection |
1-1/4 in Rotolock |
| Sound & Vibration Level |
Low |
| Weight |
66 lb |
Information About ZF09K4E-TFD-961
The ZF09K4E-TFD-961 is part of Copeland’s ZF series scroll compressors, developed specifically for low-temperature refrigeration systems requiring high reliability and efficiency. This series is approved for multi-refrigerant use and incorporates advanced scroll technology to handle liquid return and demanding operating conditions. The compressor features liquid injection to improve reliability and thermal stability during low-temperature operation. Its compact and lightweight construction simplifies installation while maintaining durable performance in commercial refrigeration environments.
Key Features:
- Low Temperature Scroll Design: Engineered specifically for low-temperature refrigeration applications with stable capacity at reduced evaporating temperatures.
- Multi-Refrigerant Approval: Compatible with multiple refrigerants, providing flexibility for system design and service requirements.
- Liquid Injection Capability: Enhances compressor cooling and reliability during low-temperature and high-load operation.
- High Isentropic Efficiency: Optimized scroll geometry improves thermodynamic efficiency and overall system performance.
- Low Noise and Vibration: Smooth scroll movement reduces acoustic output and mechanical stress.
- Compact and Lightweight Construction: Simplifies handling and installation without sacrificing durability.
- Internal Motor Protection: Built-in overload protection safeguards the compressor against abnormal operating conditions.
The ZF09K4E-TFD-961 delivers the reliability and precision required for low-temperature commercial refrigeration scroll compressor applications.
