The WyreStorm NetworkHD NHD-400-RX v3 is a 4K AV-over-IP decoder using JPEG 2000 technology. The primary hardware distinction of the v3 is the move to a 5-pin Phoenix connector for analog audio output, whereas the v2 used a 3.5mm jack.
Specifications
Model Number: NHD-400-RX v3
Brand: WyreStorm
Alt Part Number(s): NHD-400-RX v3
Product Type: Decoder
Technical Description
Brand: WyreStorm
Model: NHD-400-RX v3
Series: NetworkHD 400
Resolution: 4K60 (3840×2160 @ 60Hz)
Networking: 1x 1GbE (RJ-45) PoE-compliant port
Video Output: 1x HDMI Out (19-pin Type A)
Audio Output: 1x 5-pin Phoenix balanced analog audio (unique to v3)
USB Extension: 2x USB 2.0 Type A device ports (max 9MB/s data rate)
HDR Support: Compatible with HDR10 and HLG
Control Ports: 1x IR TX, 1x IR RX, and 1x 4-pin Phoenix for bidirectional RS-232
Encoding: JPEG 2000
Power: PoE (802.3af) or 12V 1A DC
Power Consumption: Max 8W
