Description
Cisco WS-C3850-24P-E is a 24-port Gigabit Ethernet switch with full Power over Ethernet Plus (PoE+) support, part of the Catalyst 3850 Series. It features Layer 3 capabilities, four optional uplink ports, and runs on the IP Services feature set.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Cisco |
| Category |
|
| Part Number |
WS-C3850-24P-E |
| Subcategory |
Managed PoE Network Switches
|
| Enclosure Type |
Rack-mountable - 1U |
| Ports |
24 x 10/100/1000 (POE+)
|
| Available PoE Power |
435W |
| Switching Capacity |
92Gbps
|
| Stack Bandwidth |
480Gbps
|
| Forwarding Performance |
68.4Mpps |
| FNF Entries |
24,000 flows |
| Maximum VLANs IDs |
1,000 |
| MAC Address Table Size |
32K |
| RAM |
4 G |
| Flash Memory |
2 G |
| Voltage Range (Auto) |
100V-240V |
| Power Consumption Of Standalone(in Watts) |
88.32 (max) |
| Weight |
7.4 kgs |
Information About WS-C3850-24P-E
The Cisco WS-C3850-24P-E is a 24-port Gigabit Ethernet Layer 3 managed switch from the Catalyst 3850 Series, designed for enterprise campus and access layer deployments. It offers full Power over Ethernet Plus (PoE+) support, advanced security features, and high availability.
Key Features:
-
Ports: 24 × 10/100/1000 Mbps Ethernet ports with PoE+ support
-
PoE Power Budget: 435W with the included 715W AC power supply
-
Uplink Options: Modular uplink slot supporting various network modules (e.g., 4 × 1G SFP, 2 × 10G SFP+)
-
Stacking: Supports Cisco StackWise-480 technology with up to 480 Gbps stack bandwidth
-
Power: Dual redundant, hot-swappable power supplies and three modular fans for redundancy
-
Software: Runs on Cisco IOS XE with IP Services feature set, offering advanced Layer 3 routing capabilities
-
Memory: 4 GB RAM and 2 GB flash memory
-
Switching Capacity: Up to 92 Gbps
-
Forwarding Rate: 68.4 Mpps
-
Unified Access: Integrates wired and wireless services on a single platform, supporting up to 100 access points and 2000 wireless clients per switch or stack
-
Advanced Security: Includes features like MACsec encryption, TrustSec, and flexible NetFlow for enhanced security and traffic monitoring
-
High Availability: Supports Stateful Switchover (SSO) and redundant power supplies for minimal downtime
-
Energy Efficiency: Complies with Energy Efficient Ethernet (EEE) standards
