Description

The Cisco WS-C2924-XL-EN is a 24-port managed Ethernet switch featuring 22 10/100 Mbps ports and 2 100BASE-FX fiber uplink ports. Designed for enterprise and branch office networks, it supports reliable Layer 2 switching with robust performance, flexible power input (120/230 VAC), and 50/60 Hz frequency compatibility





Technical Specifications

Condition	New/Never Used Surplus
Brand	Cisco
Category	Computer Accessories
Part Number	WS-C2924-XL-EN
Subcategory	Network Devices
Number of Ports	24 Ports
Ethernet Ports	22 x 10/100 Mbps
Fiber Ports	2 x 100BASE-FX
Power Supply	120/230 VAC
Frequency	50/60 Hz
Weight	2.91 kgs





Information About WS-C2924-XL-EN

The Cisco WS-C2924-XL-EN is a member of the Catalyst 2900 XL Series of fixed-configuration switches, designed for small to medium-sized networks. It offers essential enterprise-class features with high reliability and manageability at the access layer.

Key Features

• Model: WS-C2924-XL-EN

• Switch Type: Managed Layer 2 Switch

• Total Ports: 24 Ethernet Ports

  • 22 x 10/100 Mbps RJ-45 Ports

  • 2 x 100BASE-FX Fiber Uplink Ports

• Performance:

  • Forwarding Rate: 6.6 Mpps (million packets per second)

  • Switching Bandwidth: 3.2 Gbps

• MAC Address Table: Supports up to 8,000 MAC addresses

• Management:

  • Web-based interface

  • CLI (Command-Line Interface)

  • SNMP support

• LED Indicators: For power, link, activity, and speed

• Stacking: Not stackable (standalone unit)

• Input Power: 120/230 VAC, 50/60 Hz (auto-ranging)

• Power Consumption: ~30 Watts

• Operating Temperature: 0°C to 40°C (32°F to 104°F)

• Humidity: 10% to 85% (non-condensing)
