Vivotek AW-FED-0500-065 Features
Hardware Specifications
-
Ethernet Ports: 5 x RJ45 Fast Ethernet Ports
-
PoE Ports: 4
-
Resolution: Megapixel/D1/VGA
-
Compression: MJPEG/MPEG-4/H.264/H.265
-
Compatible Cameras: VIVOTEK Network Cameras (FD8381-EV, IB8381-E, FE8181/81V, FE8391 excluded)
-
Power Requirement: 100~240VAC / 50~60Hz, 56VDC/1.16A
-
Power Consumption: 65W
-
LED Display: Power, Uplink, LAN ports x4, PoE ports x4
-
Dimensions: 120 (L) x 90 (W) x 28 (H) mm
-
Weight: 0.4 kg (0.88 lbs)
-
Operating Temperature: 0°C ~ 50°C (32°F ~ 122°F) with 10~90% RH (Non-condensing)
What's Included: Power cord, power adapter, QIG, wall mount kit
- Warranty: 2 years
Power over Ethernet Specifications
-
Filtering/Forwarding Rates: 10Mbps/100Mbps
-
Switch Throughput: N/A
-
Per Port PoE Power Output: 52W Max
-
Total PoE Power Budget: 60W
-
Transmission Method: Store & forward
-
PoE Power Supply Type: End-Span
-
Power Pin Assignments: 4/5(+), 7/8(-)
-
Regulation Compliance: CE, C-Tick, FCC, LVD, VCCI
-
Standards Compliance: IEEE 802.3 10-BASE-T (Ethernet), IEEE 802.3u 100-BASE-TX (Fast Ethernet), IEEE 802.3x Flow Control (Full-Duplex Flow Control), IEEE 802.3af Power over Ethernet, IEEE 802.3at Power over Ethernet Plus
