Product Specifications



Camera Features



Image Sensor	1 / 2.3″ Progressive CMOS
Sensor Resolution1	12MP (4056 x 3040); active pixels (3008 x 3008)

Lens Type	Fixed
Focal Length	1.18mm

Aperture	F2.18
Iris	Fixed

Field of View (after LDC2)	Horizontal: 180° Vertical: 180° Diagonal: 180°
Sensor Movement	N/A

Shutter Speed	1 / 30 sec. to 1 / 16,000 sec.
Day/Night	IR-cut filter for day and night function

IR Cut Filter	Yes
IR Range	20m / 66ft

Minimum Illumination	0.009 lux @ F1.9 (Color) 0 lux with IR Illuminators on
Onboard Storage	Capacity: From 512GB to 3TB Card: MicroSD, SDXC

CPU	Ambarella CV72S66

Standard video settings

Compression	H.265, H.264
Frame Rate4	24fps

Live Streaming Settings	High quality (HQ): Up to 4,500 Kbps (default) Standard quality (SQ): Up to 600 Kbps
Historical Video Settings	Adaptive quality1

WDR Technology	120dB dynamic range, true WDR, dual exposure

Standard audio settings

Audio	Supported
Audio Capacity	One-way audio

Interface	Built-in microphone
Effective Range	5m / 15ft

Power and Network

Power Input3	With IR: IEEE 802.3at Type 2 PoE+ Extended temperature range: IEEE 802.3at Type 2 PoE+
Power Consumption3	With IR: 42.5 - 57V, 0.46-0.34A, 19.9W Without IR: 42.5 - 57V, 0.22-0.17A, 9.5W Extended temperature range: 42.5 - 57V, 0.59A - 0.44A, 24.8W

Connectivity	RJ-45 cable connector for network/PoE connection; 10 / 100 / 1000 Mbps
RTSP	RTSP 1.0 RFC 2326 Max concurrent streams: 2 Audio support: No

General

Operating Temperature	-40°C to 50°C / -40°F to 122°F
Humidity	0 to 90%

Certifications	FCC, ICES, IK10 impact rating, IP66/IP67 weather rating
LED Indicator	System power, status indicator, and debug indicator

Warranty	10 years
Included Accessories	Screw packs, mount plate with leveler, cable sealing rubber for 6.5-7.5mm, conduit adapter, T10 security driver

Mechanical

Weight	Camera: 1368g / 48.2oz Mount plate: 196g / 6.9oz
Dimensions	Ø: 155mm / 6.10in, H: 76.2mm / 3.0in with mount plate Ø: 155mm / 6.10in, H: 69.2mm / 2.72in without mount plate

Body	Aluminum, plastic dome trim

Software Capabilities

Alerts4	Camera status, motion detection, people detection, vehicle detection, Person of Interest detection, crowd detection, AI-powered alerts
People Analytics4	People search, attribute search, face search, motion search, trajectory analysis, selective face blurring, AI-powered search5

Vehicle Analytics4	Vehicle search, attribute search, motion search, trajectory analysis, AI-powered search
Streaming and storage4	Cloud backup, configurable retention days, selectable storage location, low bandwidth mode, timelapse, RTSP

Sharing and privacy4	Live Links, privacy regions, audit log
Verkada	Video Security Camera System

1. All our cameras record in "adaptive quality", capturing both standard and high quality streams. Standard quality (SQ) video is stored up to the amount of retention specified by the customer. The amount of high quality video stored on the camera will depend on the amount of motion detected by the camera over time.
2. Extended temperature range includes operating temperatures below -8.5°C / 16.7°F and assumes IR will be enabled.
3. Frame rate can be adjusted by support.
4. Trajectory analysis is supported in four-way split, panoramic, and ePTZ circle mode
5. AI-powered search is currently supported in English only.
