[shortdesc]
- 48, Switch, managed, 48 x 10/100/1000 + 2 x 10 Gigabit SFP+ + 2 x Gigabit SFP, rack-mountable
[/shortdesc]
[properties]
| Properties |
Ubiquiti US-48 Switch (US-48) |
| Description |
Non-Blocking Throughput Switching Performance |
| Product Family |
Ubiquiti Unifi Switch |
| Product Type |
Switch |
| Overview |
|
| Non-Blocking Throughput |
70 Gbps |
| Switching Capacity |
140 Gbps |
| Forwarding Rate |
104.16 Mpps |
| Maximum Power Consumption |
56W |
[/properties] [specifications]
| Specifications |
Ubiquiti US-48 Switch (US-48) |
| Dimensions |
443 x 43 x 221 mm (17.44 x 1.69 x 8.70") |
Weight
With Rackmount Brackets |
3.56 kg (7.85 lb)
3.65 kg (8.06 lb) |
| Gigabit RJ45 Ports |
48 |
| Networking Interfaces |
(48) 10/100/1000 Mbps RJ45 Ethernet Ports
(2) 1/10 Gbps SFP+ Ethernet Ports
(2) 1 Gbps SFP Ethernet Ports |
|
|
| Management Interface |
(1) RJ45 Serial Port Out-of-Band, Ethernet In-Band |
| Total Non-Blocking Throughput |
70 Gbps |
| Switching Capacity |
140 Gbps |
| Forwarding Rate |
104.16 Mpps |
| Power Method |
100-240VAC/50-60 Hz, Universal Input |
| Power Supply |
AC/DC, Internal, 56W DC |
| Max. Power Consumption |
56W |
| LEDs per Port |
Speed/Link/Activity |
| Sound Level* |
Fan Level: 0 - 0.7 dBr
Fan Level: 1 - 13.5 dBr |
| ESD/EMP Protection |
Air: ± 24 kV, Contact: ± 24 kV |
| Rack Mount |
Yes, 1U High |
| Shock and Vibration |
ETSI300-019-1.4 Standard |
| Operating Temperature |
(-5 to 40° C (23 to 104° F)) |
| Operating Humidity |
5 to 95% Noncondensing |
| Certifications |
CE, FCC, IC |
[/specifications] [accesories] [/accesories] A single instance of the UniFi Controller running in the cloud can manage multiple UniFi sites within a centralized interface. Each site is logically separated and has its own network monitoring, configuration, maps, statistics, and admin accounts.
The SFP ports support uplinks of up to 1 Gbps. For high-capacity uplinks, each 48-port model includes two SFP+ ports for uplinks of up to 10 Gbps.
The UniFi Switch offers the forwarding capacity to simultaneously process traffic on all ports at line rate without any packet loss.
