Overview
The TLC Distribution Fiber Optic Cable is designed for indoor applications requiring mechanical protection. This cable features six singlemode fibers utilizing Corning SMF-28 Ultra technology, encased in an aluminum interlocking armor layer for increased crush resistance and durability. The cable is jacketed in a yellow plenum-rated material, suitable for installation in air handling spaces.
Key Features
-
Corning SMF-28 Ultra Fiber: Utilizes standardized singlemode glass compatible with existing infrastructure for consistent transmission characteristics.
-
Aluminum Interlocking Armor: Provides a robust mechanical barrier to protect fibers against physical impact and crushing during installation or use in high-traffic areas.
-
900um Tight Buffered Fibers: Allows for direct termination of connectors onto the fibers, eliminating the requirement for additional breakout kits.
-
Plenum-Rated Jacket: Features a fire-retardant outer sheath that meets safety requirements for installation within environmental air spaces.
-
6-Fiber Construction: Provides six distinct signal pathways within a single cable structure for network cabling density.
Technical Specifications
| Attribute |
Specification |
| SKU |
S09DI06CZNPYAIA |
| Fiber Count |
6 |
| Fiber Type |
Singlemode (Corning SMF-28 Ultra) |
| Cable Type |
Distribution |
| Armor Type |
Aluminum Interlocking Armor |
| Jacket Rating |
Plenum (OFCP) |
| Jacket Color |
Yellow |
| Outer Diameter (OD) |
14.15 mm |
| Fiber Construction |
900um Tight Buffered |
| Unit of Measurement |
Meter |
