Description
The Omron TJ1-ML04 Master Unit is a MECHATROLINK-II communication controller designed for high-speed motion control and system coordination. Operating at a transmission speed of 10 Mbps, it supports up to four connected stations for servo drive or I/O device management. Featuring a USB port for configuration and monitoring, this DIN-rail-mounted module enables efficient communication between Omron Trajexia motion controllers and networked devices.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Industrial Automation and Controls |
| Part Number |
TJ1-ML04 |
| Subcategory |
Communication and Network Modules |
| Series |
Trajexia Series |
| Type |
MECHATROLINK-II Master Unit |
| Communication Protocol |
MECHATROLINK-II |
| Maximum Stations Supported |
4 |
| Transmission Speed |
10 Mbps |
| Interface Ports |
MECHATROLINK-II Connector, USB Port |
| Power Supply Voltage |
24 VDC (typical for Trajexia system) |
| Mounting Type |
DIN Rail Mount |
| Connection Type |
Plug-in terminal or connector-based (system dependent) |
| Function |
Master communication controller for servo/I-O devices |
| Compatibility |
Trajexia Motion Controller Series |
| Operating Temperature Range |
0°C to +55°C |
| Storage Temperature Range |
-20°C to +70°C |
| Protection Rating |
IP20 (panel-mounted environment) |
| Status |
Discontinued by Manufacturer |
| Enclosure Material |
Industrial-grade housing |
| Dimensions (Approx.) |
Compact DIN-rail module format |
| Weight |
Approx. 0.35 kg (0.77 lb) |
Information About TJ1-ML04
The TJ1-ML04 belongs to Omron’s Trajexia Series, a powerful motion control platform designed for multi-axis synchronization and precise automation control. As a MECHATROLINK-II master/head unit, it supports up to four slave stations, facilitating fast, deterministic communication between drives and control units. Its 10 Mbps transmission rate ensures high-speed data exchange for real-time motion commands and feedback. The built-in USB interface allows direct connection to configuration tools for programming, diagnostics, and maintenance. Compact and reliable, the unit mounts easily on a DIN rail for integration into industrial control systems.
Key Features:
- MECHATROLINK-II Master: Controls up to four stations for servo and I/O communication.
- High-Speed Data Transfer: Operates at a 10 Mbps transmission rate for responsive motion control.
- USB Interface: Enables configuration, monitoring, and data management through direct PC connection.
- DIN-Rail Mount Design: Simplifies installation in industrial control panels.
- Reliable Omron Communication: Ensures stable, deterministic networking between motion components.
- Compact Construction: Space-saving housing ideal for multi-axis control environments.
- Trajexia Platform Integration: Fully compatible with Omron Trajexia motion controllers.
- Industrial Durability: Designed for continuous operation in automation and machine control systems.
The TJ1-ML04 delivers the reliability and precision required for high-performance motion control, servo synchronization, and distributed automation networks.
