[shortdesc]
- Ethernet Switch
- Teltonika TSW114
- Robust Performance
- Reliable Networking
- High-Speed Data Transfer
[/shortdesc]
[properties]
| Properties |
TSW114 SWITCH (TSW114000000) |
| Description |
Streamline connectivity with TSW114's 5 Gigabit Ethernet ports. Effortless installation in industrial environments, perfect for control cabinets. |
| Product Family |
Teltonika TWS Switches |
| Product Type |
Switch |
| PoE standard |
802.3af/at (max 30 W per port, total power budget 60W) |
| Ethernet |
5 x RJ45 ports, 10/100/1000 Mbps |
| Housing |
Anodized aluminum housing and panels |
| Dimensions |
113.1 x 27.4 x 80.5 mm |
| Weight |
174 g |
| Mounting |
Integrated DIN rail bracket, wall mounting (additional kit needed), flat surface placement |
| Input voltage range |
9 - 30 VDC |
| Power consumption (idle/max no PoE/max) |
Idle: 0.3 W / Max: 2.3 W |
[/properties] [specifications]
| Bandwidth |
10 Gbps |
| Packet buffer |
128 KB |
| MAC address table size |
2K entries |
| Jumbo frame support |
9216 bytes |
| Status LEDs |
1 x Power LED, 10 x LAN status LED’s |
| Ingress protection rating |
IP30 |
| Operating temperature |
-40 °C to 75 °C |
| Operating humidity |
10 % to 90 % non-condensing |
| Regulatory |
CE, REACH, RoHS, WEEE UKCA, FCC, IC, CB, RCM |
| Safety Standards |
EN IEC 62368-1:2020+A11:2020 |
[/specifications] [accesories] [/accesories]
The Teltonika TSW114 Ethernet Switch offers robust performance and reliable networking. Ideal for demanding environments, it ensures high-speed data transfer and efficient connectivity. Trust the TSW114 for high-quality, reliable networking.
