Description
TAP1020-01 is a rugged I/O expansion tap module used for distributed control in industrial automation networks. It enables localized connection of power and communication to field-mounted I/O modules, ensuring robust performance in decentralized systems.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Honeywell |
| Category |
|
| Part Number |
TAP1020-01 |
| Subcategory |
Field-Mount Tap Modules |
| Product Series |
A700x |
| Mounting |
Through-hole |
| Housing Material |
Cast aluminum |
| Enclosure Rating |
IP67 |
| Operating Voltage |
10–30 VDC |
| Interfaces |
M12 (power and I/O) |
| Operating Temperature |
–40°C to +70°C |
| Storage Temperature |
–40°C to +85°C |
| Humidity Range |
0–95% RH non-condensing |
| Vibration/Shock Resistance |
IEC 60068-2 compliant |
| Diagnostic Capability |
May include local status indicators |
| Application |
Distributed I/O expansion for A700x systems |
| Dimensions |
Approx. 110 x 35 x 30 mm |
| Weight |
Approx. 0.3–0.4 kg (0.66–0.88 lbs) |
Information About TAP1020-01
The TAP1020-01 is a field-mountable tap module from the A700x series designed for use in harsh industrial environments. It provides an efficient interface for distributing both data and power to I/O devices over M12 connectors. The unit is built with a compact, IP67-rated aluminum housing suitable for exposed field conditions. It is typically used in modular, scalable control architectures requiring fast deployment and reliable connectivity.
Key Features:
- Field-Ready Enclosure: Cast aluminum housing rated for IP67 protection against dust and water.
- M12 Connectivity: Equipped with rugged M12 connectors for both power and communication links.
- Modular Expansion: Supports distributed I/O topologies for scalable automation systems.
- High Durability: Operates reliably in extreme temperatures and industrial shock/vibration environments.
- 24 VDC Operation: Accepts a 10–30 VDC supply range for flexible field power integration.
- Wide Compatibility: Compatible with A700x controllers and industrial I/O-link devices.
- Simple Mounting: Through-hole mounting design allows for wall or panel installation.
- Plug-and-Play Setup: Supports quick connection and configuration in field installations.
- Sealed Design: Suitable for outdoor and washdown applications in process or discrete industries.
- Diagnostic Ready: May include status indicators for fault isolation and system monitoring.
The TAP1020-01 delivers the reliability and precision required for modern distributed control networks.
