This is a genuine Supermicro 4-Bay 2.5" Hybrid Backplane (P/N: BPN-NVME3-802N-S4). This direct-attach backplane is designed for high-performance storage solutions in specific Supermicro 1U server chassis. It provides flexible connectivity for a mix of U.2 NVMe and SAS/SATA drives, but is optimized for all-flash NVMe configurations. A critical detail for this backplane is its support for drives with a maximum height of 7mm.
Key Features
-
Hybrid Drive Support: Features four 2.5" bays that support high-speed U.2 NVMe SSDs as well as traditional 12Gb/s SAS3 and 6Gb/s SATA drives.
-
Direct-Attach Performance: This is a direct-attach backplane, ensuring a dedicated PCIe data path to each NVMe drive for the lowest possible latency and maximum performance.
-
7mm Drive Height: Specifically designed for slim, 7mm height 2.5-inch drives, which is a critical compatibility requirement.
-
Hot-Swap Capability: Fully supports hot-swap functionality, allowing for drive installation and replacement without server downtime.
-
Genuine Supermicro Part: Ensures perfect fit and function within compatible Supermicro server systems.
