Description
The System Sensor SPSCWL-BP10 is a white wall-mount speaker strobe designed for clear voice evacuation and visible notification in fire alarm and emergency communication systems. It combines a high-fidelity speaker with a synchronized LED strobe for reliable performance in life safety applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
System Sensor |
| Category |
Notification Appliances |
| Part Number |
SPSCWL-BP10 |
| Subcategory |
Speaker Strobe |
| Series |
L-Series |
| Product Type |
Wall-mount speaker strobe |
| Mounting Type |
Wall mount |
| Color |
White |
| Voltage |
25 or 70.7 VRMS (selectable) |
| Power Taps |
Field-selectable (1/8 W, 1/4 W, 1/2 W, 1 W, 2 W) |
| Strobe Type |
LED, synchronized |
| Strobe Candela Rating |
15, 30, 75, 95, 115, 150 cd (model dependent) |
| Speaker Frequency Range |
400–4000 Hz |
| Sound Output |
High-fidelity audio for voice evacuation |
| Input Terminals |
Plug-in screw terminals for quick wiring |
| Operating Temperature |
32°F to 120°F (0°C to 49°C) |
| Humidity |
10%–93% RH, non-condensing |
| Compliance |
UL 1480, UL 1971, NFPA 72, ADA |
| Dimensions |
6.5" H × 5" W × 2.5" D (approx.) |
| Weight |
1.2 lbs (approx.) |
Information About SPSCWL-BP10
The SPSCWL-BP10 is part of System Sensor’s L-Series line of notification appliances, engineered for high intelligibility and energy efficiency. Designed for wall-mount installation, it delivers clear voice messages and tone signals while providing bright, synchronized strobe illumination for visual alerting. The unit supports 25 or 70.7 VRMS operation with field-selectable power taps to suit a wide range of sound output requirements. Featuring a white finish and low-profile design, the SPSCWL-BP10 is ideal for commercial buildings, schools, hospitals, and office facilities requiring both audible and visual notification in compliance with NFPA and ADA standards.
Key Features:
- Integrated Speaker and Strobe: Combines audible and visual signaling for comprehensive notification.
- L-Series Platform: Provides high intelligibility and energy-efficient LED strobe output.
- Selectable Voltage: Operates on 25 or 70.7 VRMS systems.
- Field-Configurable Output: Multiple wattage taps for customized sound levels.
- White Wall Mount Design: Sleek, modern aesthetic suitable for visible installation areas.
- Synchronized Strobe: Meets ADA and NFPA 72 requirements for temporal and visual alerting.
- Durable Construction: Built for long-term reliability in commercial environments.
- Easy Installation: Plug-in design with mounting plate for fast field wiring.
The SPSCWL-BP10 delivers the reliability and precision required for effective fire alarm and emergency voice evacuation notification.
