Description
Product description
The SFP-7000-85 is a 1000Base-SX multi-mode Gigabit Ethernet rate SFP transceiver using 850nm wavelength and reaching up to 550m distance on 50/125um fiber or up to 275m on 62.5/125um fiber.
The SX standard is one of the most popular for short range fiber connections due to widespread usage of multi-mode fiber for inside and inter building networking and also because of the very affordable costs.
Transceivers have been tested for compatibility with a large variety of networking devices from well known brands like: Cisco, Juniper, Force10, Edge-Core, ZyXEL, D-Link and many others.
The transceivers follow the industry standards of SFP Multi-Source Agreement (MSA) and SFF-8472, making them directly interchangeable with any networking device following industry standards.
The SFP-7000-85 has Digital Diagnostic Monitoring Interface built-in into the unit. All transceivers support DDM features.
All Gigabit series SFP based converters like FMC-1000S, FRM220-1000TS, FRM220-1000MS and FMC-1000MS as well as Gigabit Industrial media converters and switches can be equipped with miniGBIC/SFP optical modules.
Additional information on available for SFP-7000-85 transceiver:
PDF datasheet
Fiber power budget according to available models
(highlighted model is one available for purchase on this page)
| Model | Distance | Lambda | Min. Output (dBm) | Sensitivity (dBm) | Power Budget (dB) |
| SFP-7000-85 | 550m | 850nm | -9.5 | -18 | 8.5 |
| SFP-7000-31 | 2Km | 1310nm | -9 | -19 | 10 |
| SFP-7010-31 | 10Km | 1310nm | -9.5 | -20 | 10.5 |
| SFP-7040-31 | 40Km | 1310nm | -4 | -24 | 20 |
| SFP-7050-55 | 50Km | 1550nm | -4 | -24 | 20 |
| SFP-7080-55 | 80Km | 1550nm | 0 | -24 | 24 |
| SFP-7120-55 | 120Km | 1550nm | 0 | -30 | 30 |
| SFP-7010-WA | 10Km | Tx:1310nm Rx:1550nm | -9 | -21 | 12 |
| SFP-7010-WB | 10Km | Tx:1550nm Rx:1310nm | -9 | -21 | 12 |
| SFP-7020-WA | 20Km | Tx:1310nm Rx:1550nm | -8 | -23 | 15 |
| SFP-7020-WB | 20Km | Tx:1550nm Rx:1310nm | -8 | -23 | 15 |
| SFP-7040-WA | 40Km | Tx:1310nm Rx:1550nm | -3 | -23 | 20 |
| SFP-7040-WB | 40Km | Tx:1550nm Rx:1310nm | -3 | -23 | 20 |
| SFP-7060-WA | 60Km | Tx:1310nm Rx:1550nm | 0 | -24 | 24 |
| SFP-7060-WB | 60Km | Tx:1550nm Rx:1310nm | -2 | -25 | 23 |
