Description

The Cisco SFP-10G-LRM is a versatile 10GBASE-LRM transceiver module supporting both multimode and single-mode fiber, ideal for short-range deployments with wide compatibility across Cisco networking devices.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Cisco
Category	Transceivers & Optical Modules
Part Number	SFP-10G-LRM
Subcatecory	10G Multimode/Single-mode Compatible Modules
Wavelength	1310 nm
Supported Fiber Types	MMF (62.5μm / 50μm), SMF (G.652)
Max Distance	220m (MMF), 300m (SMF G.652)
Transmit Power	-6.5 to 0.5 dBm
Receive Power	-8.4 (avg) to 0.5 dBm
Connector Type	LC Duplex
Form Factor	SFP+
Power Consumption	1 W
Temperature Range	0°C to 70°C (32°F to 158°F)
Dimensions (H x W x D)	8.5 x 13.4 x 56.5 mm





Information About SFP-10G-LRM

The SFP-10G-LRM is a 10GBASE-LRM transceiver module designed by Cisco for 10 Gigabit Ethernet over both multimode (MMF) and single-mode fiber (SMF). Operating at a 1310 nm wavelength, this module ensures robust data transmission for short-distance links across various fiber types, including 62.5μm, 50μm, and G.652 single-mode cores. It supports distances of up to 220 meters over OM3 fiber and up to 300 meters over G.652 single-mode fiber, making it suitable for data centers, enterprise wiring closets, and campus networks.

Key Features:

• 10GBASE-LRM Standard: Optimized for multimode and single-mode fiber

• 1310 nm Wavelength: Supports diverse deployment scenarios

• Versatile Cable Support: Compatible with MMF (50μm, 62.5μm) and SMF (G.652)

• Medium Range Distances: Up to 300m reach depending on fiber type

• Compact Design: SFP+ form factor for dense port environments

• Energy Efficient: Power consumption of just 1W

• Commercial Temperature Range: 0°C to 70°C for standard IT environments

• Hot Swappable: Enables easy upgrades and replacements without downtime

The SFP-10G-LRM provides a flexible and efficient optical transceiver option for Cisco-based 10Gbps Ethernet networks.
