The Schneider Electric (Square D) QMB323HD is a QMB Series D2 panel mount switch rated 100 A, 3-pole, 240 VAC. It provides 200kA@240V interrupting rating.
Factory specification: panel mount, 3PH, 3P, 240V, 100A, 200kA@240V, nema 1, Fusible Single style, complete with rear stab in base connectors, accepts class R,H,K fuses, suitable for use with QMB series D2 panel boards and switchgear distribution systems.
QMB323HD Technical Specifications
| Manufacturer |
Schneider Electric (Square D) |
| Series |
QMB Series D2 |
| Type |
Panel Mount Switch |
| Voltage |
240 V |
| Amperage |
100 A |
| Poles |
3 |
| Phase |
3 |
| AIC Rating |
200kA@240V |
| Nema Rating |
1 |
| Configuration |
Single |
| Switch Style |
Fusible |
| Suit Fuse |
R,H,K |
The QMB323HD is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
