The Schneider Electric (Square D) QMB222HWPD is a QMB Series E1-E2 panel mount switch rated 60 A, 2-pole, 240 VAC. It provides 200kA@240V interrupting rating.
Factory specification: panel mount, 1PH, 2P, 240V, 60A, 200kA@240V, nema 1, Fusible Single style, power distribution, accepts class R,H,K fuses, suitable for use with QMB series E1 & E2 panel boards and switchgear distribution systems.
QMB222HWPD Technical Specifications
| Manufacturer |
Schneider Electric (Square D) |
| Series |
QMB Series E1-E2 |
| Type |
Panel Mount Switch |
| Voltage |
240 V |
| Amperage |
60 A |
| Poles |
2 |
| Phase |
1 |
| AIC Rating |
200kA@240V |
| Nema Rating |
1 |
| Configuration |
Single |
| Switch Style |
Fusible |
| Suit Fuse |
R,H,K |
The QMB222HWPD is available from Industrial Automation Co. in New and IAC Certified Refurbished condition. Contact our sales team for current availability, pricing, and lead time.
