Description
The Schneider Electric DP-4075 is a 20A tandem circuit breaker designed to provide reliable overload and short-circuit protection for residential and light commercial electrical distribution systems. Its compact tandem configuration delivers two independent single-pole 20A circuits within a single panel space, maximizing load center capacity without requiring additional panel expansion. The breaker is intended for use in compatible Schneider Electric Homeline load centers and CSED devices.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Schneider Electric |
| Category |
Circuit Breaker |
| Part Number |
DP-4075 |
| Subcategory |
Tandem Circuit Breaker |
| Series |
Homeline |
| Configuration |
Tandem (2 × Single-Pole) |
| Current Rating |
20 A per pole |
| Voltage Rating |
120/240 VAC |
| Interrupting Rating (AIR) |
10 kA |
| Trip Type |
Thermal-Magnetic |
| Installation |
Plug-On |
| Compatible Equipment |
Homeline Load Centers and CSED Devices |
| Certifications |
UL Listed, ANSI Certified |
| Application |
Branch Circuit Protection |
| Weight |
0.55 lb (0.25 kg) |
Information About DP-4075
The DP-4075 is a tandem 20 Amp single-pole circuit breaker, engineered for efficient space utilization within Homeline load centers and CSED devices. Designed to fit into a single pole space, it provides two independent 20A breakers, ideal for expanding circuit capacity without altering the panel layout. With a plug-on installation design, this breaker simplifies panel upgrades and maintenance while delivering secure and consistent electrical contact. Rated for 120/240 V AC and 10,000 AIR (Ampere Interrupting Rating), the device meets ANSI standards and is UL listed for compliance and safety. Its compact profile and performance make it a go-to solution for modern residential installations.
Key Features:
- Tandem Configuration: Provides two independent 20A single-pole breakers in one panel space.
- Thermal-Magnetic Protection: Protects against overloads and short circuits.
- Plug-On Installation: Allows quick installation in compatible Homeline load centers.
- Space-Saving Design: Expands available circuits without enlarging the electrical panel.
- 120/240 VAC Compatibility: Suitable for standard residential branch circuit applications.
- 10 kA Interrupt Rating: Provides dependable fault interruption capability.
- UL Listed Construction: Meets recognized safety and performance standards.
- Homeline Compatibility: Designed for Schneider Electric Homeline load centers and CSED devices.
The DP-4075 delivers the reliability and precision required for safe branch circuit protection in residential and light commercial electrical distribution systems.
