Description
The Omron R7D-AP04H is a 400 W single-phase AC servo drive designed for precise and efficient motion control. Operating on 200–230 VAC, it delivers a rated output current of 5.5 A and an adjustable output voltage up to 230 VAC for reliable motor operation.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Motion Control |
| Part Number |
R7D-AP04H |
| Subcategory |
Servo Drives |
| Series |
R7 |
| Product Type |
Servo Drive |
| Power (Rated) |
400 W |
| Output Voltage |
0–230 VAC |
| Current (Rated) |
5.5 A |
| Voltage (Input) |
200–230 VAC |
| Phase |
Single-phase |
| Frequency |
50/60 Hz |
| Control Method |
Pulse input |
| Protection Class |
IP20 |
| Approval Agencies |
cUL, UL |
| Operating Temperature |
0°C to 40°C |
| Weight |
0.50 kg |
Information About R7D-AP04H
The R7D-AP04H is part of Omron’s R7 series of servo drives, engineered to meet demanding industrial motion control requirements. Designed for single-phase operation, it supports a rated power output of 400 W and provides an output voltage range from 0 to 230 VAC, enabling smooth speed and torque control for compatible servo motors. With a pulse input control method, it allows precise positioning and motion management, while its compact IP20-protected housing facilitates installation in protected industrial environments. Operating in temperatures from 0°C to 40°C, this servo drive is approved by cUL and UL, ensuring compliance with international safety standards.
Key Features:
-
400 W Rated Output Power: Delivers reliable performance for medium-duty motion control applications.
-
Single-Phase 200–230 VAC Input: Compatible with common industrial power supplies for easy integration.
-
Rated Output Current of 5.5 A: Provides consistent power for smooth servo motor operation.
-
Adjustable Output Voltage Range: Outputs from 0 to 230 VAC for flexible motor control.
-
Pulse Input Control Method: Supports precise positioning and responsive motion control.
-
Compact IP20 Housing: Protects internal components while fitting easily into control panels.
-
International Safety Approvals: Certified by cUL and UL for safe global use.
-
Lightweight Construction: Weighs only 0.50 kg for simplified installation and handling.
-
Stable Operating Range: Functions effectively in environments from 0°C to 40°C.
The R7D-AP04H delivers the reliability and precision required for efficient, responsive servo motor control in industrial automation.
