Description
The Omron R7D-AP01H is a 100 W servo driver from the R7 series, built for single-phase 200 VAC systems and designed to drive SmartStep A Series servo motors. Utilizing PWM control with IGBT technology, it supports precise pulse input control and operates within a compact IP20-rated chassis.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Motion Control |
| Part Number |
R7D-AP01H |
| Subcategory |
Servo Drives |
| Series |
R7 |
| Voltage - Supply |
200 VAC (single-phase) |
| Voltage - Load |
200 V |
| DC Control Voltage |
24 VDC |
| Input Type |
Pulse Input |
| Output Current |
0.89 A |
| Input Current |
2 A |
| Rated Power Output |
100 W |
| Control Method |
PWM with IGBT |
| Protection Rating |
IP20 |
| Mounting Type |
DIN Rail / Chassis Mount |
| Operating Temperature |
0°C to 55°C |
| Interface |
Serial |
| Number of Motors Supported |
1 |
| Certifications |
UL, cUL |
| For Use With |
SmartStep A Series |
| Weight |
1.8 lbs (816.5 g) |
Information About R7D-AP01H
The R7D-AP01H is a servo drive module from Omron’s R7 series, optimized for small-scale automation tasks requiring high-speed, accurate motor control. Designed for use with SmartStep A Series motors, it supports single-phase 200 VAC input and outputs up to 0.89 A, delivering up to 100 W of power. The unit employs a pulse-width modulation (PWM) control method using an IGBT switching element, ensuring efficient and smooth motor operation. Compatible with DIN rail or chassis mounting, the R7D-AP01H integrates into control panels with minimal footprint and supports pulse input interfacing for position or speed control.
Key Features:
-
PWM Control with IGBT Switching: Ensures stable and responsive motor control using high-efficiency pulse-width modulation.
-
Pulse Input Interface: Accepts pulse signals for accurate positioning and speed regulation in servo applications.
-
Compact Single-Phase Design: Operates with 200 VAC single-phase power input and supports small motor loads up to 100 W.
-
Versatile Mounting Options: Can be mounted on DIN rail or directly on chassis to suit different panel configurations.
-
IP20 Protection Rating: Protected against solid objects over 12.5 mm, suitable for enclosed cabinet installations.
-
Wide Operating Temperature: Functions reliably in environments ranging from 0°C to 55°C.
-
Agency Approvals: Certified by UL and cUL for compliance with international safety standards.
-
Compact & Lightweight: Weighs only 1.8 lbs, facilitating easy installation and handling in space-constrained applications.
The R7D-AP01H delivers the reliability and precision required for accurate, space-efficient motion control in industrial automation systems.
