Description
The Cisco QSFP-100G-LR4 is a 100GBASE-LR4 optical transceiver module that delivers long-range, high-speed connectivity over single-mode fiber. It supports 100 Gbps transmission up to 10 km with an LC duplex connector.
Technical Specifications
|
Condition
|
New/Never Used Surplus
|
| Brand |
Cisco
|
| Category |
|
| Part Number |
QSFP-100G-LR4
|
| Subcatecory |
|
| Form Factor |
QSFP28 |
| PHY Type |
IEEE 802.3bm 100GBASE-LR4 |
| Fiber Type |
Single-mode Fiber (SMF) |
| Connector Type |
Duplex LC |
| Wavelength |
1310 nm |
| Max Distance |
10 km |
| Hot Swappable |
Yes |
| Operating Temperature |
0°C to 70°C |
| Dimensions (H x W x D) |
18.4 x 13.5 x 72.4mm |
| Weight |
100g |
Information About QSFP-100G-LR4
The QSFP-100G-LR4 is a QSFP28 transceiver module designed in compliance with IEEE 802.3bm 100GBASE-LR4 standards, providing 100 Gbps Ethernet connectivity over single-mode fiber (SMF). Operating at a 1310 nm wavelength, it supports distances up to 10 kilometers, making it ideal for long-haul backbone links in data centers and enterprise networks.
Key Features:
-
High-Speed 100G Transmission: Supports up to 100 Gbps across 10 km over single-mode fiber
-
IEEE Compliance: Built to IEEE 802.3bm 100GBASE-LR4 specifications for seamless interoperability
-
1310 nm Wavelength: Operates on four wavelengths within the 1310 nm window for long-distance communication
-
Standard LC Connector: Uses a duplex LC interface for easy integration with existing fiber infrastructure
-
Hot-Swappable Design: Allows for non-disruptive installation and upgrades
-
Wide Compatibility: Works with Cisco QSFP28 ports on a range of switches and routers
The QSFP-100G-LR4 provides reliable, high-bandwidth fiber connectivity for long-distance 100G deployments in enterprise and service provider environments.
