Description
ProSoft PLX51-HART-4I Input Module, 4-channel HART analog input module for Ethernet/IP and Modbus TCP/IP networks. Enables integration of HART-enabled field devices into control systems for advanced diagnostics and data acquisition.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
ProSoft |
| Category |
Data Control |
| Part Number |
PLX51-HART-4I |
| Subcategory |
Interbus Modules & Hubs |
| Mounting |
Chassis |
| Type |
Hart Module |
| Channels |
4 |
| Protocol Support |
Ethernet/IP, Modbus TCP/IP, DNP3 Ethernet |
| Resolution |
12-bit |
| Communication Port |
RJ45 |
| Input Current |
34 mA |
| Weight |
0.62 kgs |
Information About PLX51-HART-4I
The ProSoft PLX51-HART-4I is a 4-channel HART input module designed to integrate HART-compatible field devices into industrial Ethernet networks, including EtherNet/IP™, Modbus® TCP/IP, and DNP3 Ethernet.
Key Features:
-
Multi-Protocol Support: Facilitates seamless communication with EtherNet/IP, Modbus TCP/IP, and DNP3 (TCP/UDP) protocols, enabling integration with various control systems.
-
Flexible Network Configurations: Supports point-to-point and point-to-multipoint (multidrop) networks, accommodating up to 7 devices per channel in EtherNet/IP networks.
-
Automatic Configuration: Offers automatic configuration in multidrop mode for Logix Controllers, simplifying setup and reducing commissioning time.
-
Legacy System Compatibility: Includes PCCC (AB-ETH) protocol support, allowing integration with legacy controllers.
-
Advanced Diagnostics: Features a built-in web server providing detailed diagnostics of system configuration, operation, and field device status, enhancing maintenance efficiency.
-
Device Management: Supports DTM (Device Type Manager) and HART Pass-through, simplifying device configuration and management using an FDT frame.
The PLX51-HART-4I is ideal for industries requiring integration of HART-enabled input devices, such as process instruments, into modern Ethernet-based control systems. Its versatility and advanced features make it suitable for applications in oil and gas, chemical processing, water treatment, and other process industries.
