Description

The Omron E5EK-AA2-500 is a digital PID process controller designed for precise temperature and process regulation in industrial automation systems. It features relay outputs and supports remote setpoint control for flexible operation. This controller is commonly used in applications requiring stable and accurate process management.



Technical Specifications

Condition	New/Never Used Surplus
Brand	Omron
Category	Industrial Automation
Part Number	E5EK-AA2-500
Subcategory	Temperature Controllers
Product Type	Digital PID Controller
Series	E5EK
Size	48 x 96 mm (1/8 DIN)
Supply Voltage	100–240 VAC
Display Type	7-Segment Digital
Output Type	Relay
Control Method	PID
Analog Output	4–20 mA (Transfer Output)
Alarm Outputs	2
Mounting Type	Panel Mount
Application	Temperature & Process Control
Country of Origin	Japan
Weight	0.55 lbs

Information About  E5EK-AA2-500

The E5EK-AA2-500 is part of Omron’s E5EK series of digital controllers, engineered for high-performance process control in industrial environments. It supports a wide range of input signals and offers advanced PID control for accurate regulation. The unit includes serial communication capability and transfer output functionality for integration into larger automation systems. Designed for panel mounting, it provides a compact and efficient solution for monitoring and controlling industrial processes.

Key Features:

• PID Control Function: Provides precise and stable process regulation
• Remote Setpoint Capability: Allows external adjustment of control parameters
• Relay Output: Enables reliable switching for control applications
• Serial Communication Support: Facilitates integration with automation networks
• Transfer Output (4–20 mA): Supports monitoring and signal transmission
• Dual Alarm Outputs: Enhances process safety and monitoring
• 7-Segment Display: Provides clear process value visualization
• Compact 1/8 DIN Design: Fits standard panel mounting configurations

The E5EK-AA2-500 delivers the reliability and precision required for temperature and process control in industrial automation systems.
