Description
The Omron NX-EC0222 is an encoder input module designed for high-speed incremental encoder signal processing within NX I/O systems. It supports two PNP incremental encoder input channels with input frequencies up to 500 kHz. This module is used in automation applications requiring precise position and speed feedback.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron Automation and Safety |
| Category |
Industrial Automation |
| Part Number |
NX-EC0222 |
| Subcategory |
Encoder Input Modules |
| Product Type |
Encoder input module |
| Series |
NX-EC Series |
| I/O System |
NX I/O Bus |
| Input Type |
Incremental encoder, PNP |
| Number of Encoder Channels |
2 |
| Max Encoder Input Frequency |
500 kHz |
| Signal Processing Modes |
Free running, synchronous, task-prioritized |
| Output Channels |
None |
| Connection Type |
Push-in (screwless) |
| Degree of Protection |
IP20 |
| Supply Voltage |
24 VDC |
| Mounting Type |
Panel-mounted |
| Module Width |
12 mm |
| Operating Application |
Motion and automation control |
| Weight |
0.22 lb (100 g) |
Information About NX-EC0222
The NX-EC0222 is part of Omron Automation’s NX-EC Series within the NX/IO family, engineered for distributed high-performance control systems. It connects to the NX I/O Bus and processes encoder signals using free-running, synchronous, or task-period-prioritized methods. The module is designed for seamless integration with NX/IO Series controllers and supports push-in wiring for efficient installation. It is commonly used in motion control, positioning, and speed monitoring applications where accurate encoder feedback is critical.
Key Features:
- Incremental Encoder Input Module: Designed to process high-speed incremental encoder signals.
- Dual Encoder Channels: Supports two independent PNP encoder input channels.
- High Input Frequency Capacity: Handles encoder input frequencies up to 500 kHz.
- Flexible Signal Processing Modes: Supports free-running, synchronous, and task-period-prioritized operation.
- NX I/O Bus Integration: Engineered for use within Omron NX/IO distributed systems.
- Push-In Wiring Connection: Screwless terminal design enables fast and secure installation.
- Compact Module Design: Narrow form factor supports high-density I/O configurations.
The NX-EC0222 delivers the reliability and precision required for high-speed encoder signal processing in advanced automation systems.
