Description

The Cisco N7K-M224XP-23L is a high-performance, high-density 24-port 10 Gigabit Ethernet module from the M2-Series, designed for the Cisco Nexus 7000 Series switches.





Technical Specifications

Condition	New/Never Used Surplus
Brand	Cisco
Category	Network Equipment
Part Number	N7K-M224XP-23L
Subcategory	Ethernet Line Cards / SFP+ Modules
Device Type	Switch - 24 ports - L3
Enclosure Type	Plug-in module
Subtype	10 Gigabit Ethernet
Ports	24 x 10 Gigabit SFP+
Switching Fabric Bandwidth	550 Gbps
MAC Address Table Size	128K entries
Jumbo Frame Support	9216 bytes
RAM	2 GB
Status Indicators	Status, link/activity
Humidity Range Operating	5 - 90% (non-condensing)
Humidity Range Storage	5 - 95% (non-condensing)
Operating Temperature Range	32-104°C
Storage Temperature Range	-40-150°C
Dimensions (WxDxH)	15.3 in x 21.9 in x 1.7 in
Weight	16.53 lbs





Information About N7K-M224XP-23L

The Cisco N7K-M224XP-23L is a high-density 24-port 10 Gigabit Ethernet module from the M2-Series, designed for the Cisco Nexus 7000 Series switches. It offers non-blocking, line-rate 10GbE connectivity via SFP+ interfaces and includes the XL Option, enabling enhanced scalability for large-scale deployments such as data centers and service provider networks.

Key Features:

• Port Density: 24 x 10 Gigabit Ethernet SFP+ ports

• Performance: Non-blocking line-rate throughput on all ports

• XL Option: Supports up to 1 million IPv4 routes and 350,000 IPv6 routes, ideal for large-scale routing tables

• Layer Support: Comprehensive Layer 2 and Layer 3 capabilities, including MPLS and IEEE 1588 Precision Time Protocol (PTP)

• Architecture: Distributed forwarding with two integrated forwarding engines delivering up to 120 million packets per second (Mpps) for IPv4 and 60 Mpps for IPv6

• Compatibility: Compatible with Cisco Nexus 7000 Series chassis, including 4-, 9-, 10-, and 18-slot models

• Hot-Swappable: Supports hot-swapping for minimal downtime during maintenance
