[shortdesc] [/shortdesc] [properties]
| Properties |
MikroTik RBSXTG-5HPacD-SA Antenna |
| Description |
The MikroTik RBSXTG-5HPacD-SA is a 5 GHz outdoor sector antenna with 19 dBi gain. It's designed for point-to-multipoint wireless setups, providing reliable and high-speed connections over long distances. The weather-resistant design makes it ideal for outdoor use. |
| Product Family |
MikroTik SXT Series Antenna |
| Product Type |
Antenna |
| Key Features |
• 5 GHz frequency with dual-polarization
• 19 dBi gain
• Outdoor sector antenna design
• Ideal for point-to-multipoint wireless setups
• Weather-resistant construction
• Provides extended coverage and strong signal strength |
[/properties] [specifications]
| Specifications |
MikroTik RBSXTG-5HPacD-SA Antenna |
| Product code |
RBSXTG-5HPacD-SA |
| Architecture |
MIPSBE |
| CPU |
QCA9557 |
| CPU core count |
1 |
| CPU nominal frequency |
720 MHz |
| RouterOS license |
4 |
| Operating System |
RouterOS |
| Size of RAM |
128 MB |
| Storage size |
128 MB |
| Storage type |
NAND |
| MTBF |
Approximately 200'000 hours at 25C |
| Tested ambient temperature |
-40°C to 70°C |
| Powering |
| Number of DC inputs |
1 (PoE-IN) |
| Supported Voltage |
15-60V |
| Max power consumption |
12 W |
| Cooling type |
Passive |
| PoE in |
802.3af/at |
| PoE in input Voltage |
12-57 V |
| Wireless specifications |
| Wireless 5 GHz Max data rate |
867 Mbit/s |
| Wireless 5 GHz number of chains |
2 |
| Wireless 5 GHz standards |
802.11a/n/ac |
| Antenna gain dBi for 5 GHz |
14 |
| Wireless 5 GHz chip model |
QCA9892 |
| Wireless 5 GHz generation |
Wi-Fi 5 |
| Ethernet |
| 10/100/1000 Ethernet ports |
1 |
| Peripherals |
| Number of USB ports |
1 |
| USB Power Reset |
Yes |
| USB slot type |
USB type A |
| Max USB current (A) |
1 |
| Other |
| PCB temperature monitor |
Yes |
| Voltage Monitor |
Yes |
| Beeper |
Yes |
| Certification & Approvals |
| Certification |
CE, FCC, IC, EAC, ROHS |
| IP |
IP54 |
| Wireless specifications (2.4 GHz) |
| 1MBit/s |
Transmit (dBm): 31
Receive Sensitivity: -96 |
| 6MBit/s |
Transmit (dBm): 28
Receive Sensitivity: -81 |
| 54MBit/s |
Transmit (dBm): 30
Receive Sensitivity: -96 |
| MCS0 |
Transmit (dBm): 22
Receive Sensitivity: -77 |
| MCS7 |
Transmit (dBm): 22
Receive Sensitivity: -72 |
[/specifications] [accesories] [/accesories]
The RBSXTG-5HPacD-SA model features a 90-degree wide beam-width sector antenna and is equipped to support 802.11ac mode. It is also compatible with all legacy RouterBOARD devices, including Nstream and Nv2 protocols, and includes a Gigabit Ethernet port. This product supports passive PoE and 802.3af/at PoE input (15-60V). The RBSXTG-5HpacD-SAr2 supports 5150-5875 range.
Quick Specs:
- 1x 10/100/1000 Ethernet port
- IP54
- 128MB RAM
- QCA9557,1 core, 720MHz CPU
Please see the related tabs for the RBSXTG-5HPacD-SA datasheet and compatible accessories.
