[shortdesc] High-performance 48-port Gigabit PoE+ switch featuring 4x 10G SFP+ and 2x 40G QSFP+ ports. [/shortdesc]
[properties]
| Model |
CRS354-48P-4S+2Q+RM |
| Brand |
MikroTik |
| Product Type |
Managed PoE+ Switch |
| Form Factor |
Rackmount 1U |
| Ethernet Ports |
48 x 1G RJ45 |
| Management Ports |
1 x 100 Mbps Ethernet |
| SFP+ Ports |
4 x 10G SFP+ |
| QSFP+ Ports |
2 x 40G QSFP+ |
| PoE Support |
Passive PoE, Low Voltage PoE, IEEE 802.3af/at (Type 1 and 2) |
| PoE Ports |
Ether1 - Ether48 |
| Max Power Consumption |
800 W |
| Max Power Consumption (No Attachments) |
85 W |
| Power Supply |
AC 100 - 240 V |
| CPU |
QCA9531, 650 MHz |
| RAM |
128 MB |
| Storage |
32 MB flash |
| Operating System |
RouterOS (License level 5) |
| Serial Port |
RJ45 |
| Dimensions |
443 x 382 x 44 mm |
| Operating Temperature |
-20C to +60C |
[/properties]
[specifications]
| Switching Capacity |
336 Gbps |
| Non-blocking Throughput |
168 Gbps |
| Forwarding Rate |
235 Mpps |
| PoE-out Standard |
IEEE 802.3af/at and Passive PoE (26 V / 53 V) |
| PoE Max per Port (26 V) |
26 W |
| PoE Max per Port (53 V) |
30 W |
| Max Total Output (26 V) |
27 A |
| Max Total Output (53 V) |
13.2 A |
[/specifications]
[accesories]
| Power Cable |
1 IEC cord |
| Mounting Kit |
K-68 screw kit |
| Rackmount Hardware |
Rackmount ears and Rear support |
| Cable Management |
Cable management brackets |
[/accesories]
High-Density PoE Switching with 40G Backbone Performance
The MikroTik CRS354-48P-4S+2Q+RM is engineered for high-demand enterprise and ISP environments that require both massive power delivery and extreme data speeds. Featuring 48 Gigabit PoE+ ports and ultra-fast 40G QSFP+ uplinks, this switch provides a reliable solution for managing complex networks. Designed specifically for system administrators, it offers high-end performance in a functional rackmount form factor.
Key Benefits & Features
-
48 PoE+ Gigabit Ports: Supports 802.3af/at and passive PoE with auto-sensing, providing up to 30W per port for access points, IP cameras, and VoIP hardware.
-
Ultra-Fast 40G Uplinks: Two 40G QSFP+ ports enable extremely fast fiber connections or high-speed linking between switches.
-
Additional 10G Connectivity: Four 10G SFP+ ports offer versatile high-speed aggregation options.
-
Massive 750W Power Budget: The integrated heavy-duty power supply ensures enough capacity for the most demanding PoE setups.
-
Enterprise-Grade Throughput: Delivers a non-blocking throughput of 168 Gbps and a total switching capacity of 336 Gbps.
-
Advanced Management: Ships with RouterOS License Level 5, giving you access to professional-grade Layer 2 and Layer 3 management features.
Ideal Use Cases
- Enterprise network backbones with high PoE device density
- ISP and Data Center edge switching
- Large-scale IP surveillance networks and high-definition VoIP systems
- Campus networks requiring 40G fiber aggregation
Technical Specifications Summary
-
Port Configuration: 48x 1G RJ45, 4x 10G SFP+, 2x 40G QSFP+
-
PoE Standards: 802.3af/at and 26V/53V Passive PoE
-
Max PoE Output: 30W (53V High Voltage)
-
Switching Capacity: 336 Gbps
-
Non-blocking Throughput: 168 Gbps
-
Forwarding Rate: 235 Mpps
-
CPU: QCA9531 650 MHz with 128 MB RAM
Upgrade Your Network Infrastructure Today
Bring high-speed 40G performance and versatile PoE management to your rack. Secure the MikroTik CRS354-48P-4S+2Q+RM and optimize your professional setup with the best price-to-performance ratio on the market.
