Description
The Honeywell M7285A1003 is a Modutrol IV series actuator designed to deliver precise motor control in HVAC systems. Operating at 120V AC with 20 VA power consumption, it features panel mounting, screw-type connectors, and a robust design for long-lasting, dependable service.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Honeywell |
| Category |
|
| Part Number |
M7285A1003
|
| Subcategory |
Modulating and Two-Position Electric Actuators |
| Series |
Modutrol |
| Input Voltage |
120 V AC |
| Power Consumption |
20 VA |
| Mounting Type |
Panel Mount |
| Connector Type |
Screw Terminals |
| Number of Contacts |
20 |
| Number of Poles |
2 |
| Upper Temperature Rating |
122°F (50°C) |
| Weight |
15.00 lbs
|
Information About M7285A1003
The M7285A1003 belongs to Honeywell’s Modutrol IV family—renowned for their durability and accuracy in damper and valve positioning applications. This two-position or modulating actuator features a 120 VAC motor with 20 VA power usage and a screw terminal connection for easy field wiring. With a panel-mount design, it offers simple integration into HVAC control cabinets. The actuator includes a two-pole configuration and operates effectively in environments up to 122°F, making it suitable for commercial and industrial climate control systems. Engineered for compatibility with a wide range of controls, the M7285A1003 ensures reliable torque output and positional accuracy for airflow and fluid regulation.
Key Features:
- Modutrol IV Motorized Control: Designed for precision damper and valve positioning in HVAC systems.
- 120V AC Operation: Runs on standard line voltage with 20 VA power consumption.
- Screw Terminals: Simplifies wiring with secure, easy-to-install connectors.
- Panel Mount Configuration: Fits cleanly into control panels or enclosures for organized installation.
- Two-Pole Design: Provides stable electrical control for modulating or switching applications.
- High-Temperature Tolerance: Rated for operation up to 122°F, suitable for mechanical room environments.
- Compatible with Various Controllers: Integrates with Honeywell and third-party HVAC control systems.
- Durable Construction: Built to deliver consistent performance in demanding environments.
The M7285A1003 combines industrial reliability with flexible mounting and control capabilities for air and fluid management.
