Description
The Banner Engineering M18TUP14Q is an infrared temperature sensor designed for non-contact temperature measurement of moving or stationary objects. It uses a 14:1 germanium optical lens and provides an analog 0–10 V output with a PNP alarm function. The sensor operates without an emitter or external controller and is suitable for industrial monitoring applications.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Banner Engineering |
| Category |
Sensors & Switches |
| Part Number |
M18TUP14Q |
| Subcategory |
Temperature Sensors |
| Series |
M18T |
| Sensor Type |
Infrared Temperature Sensor |
| Optical Ratio |
14:1 |
| Remote Sensing Temperature Range |
0°C to 300°C |
| Ambient Operating Temperature |
-20°C to +70°C |
| Analog Output Configuration |
0–10 VDC |
| Alarm Output Type |
PNP |
| Supply Voltage |
12–30 VDC |
| Response Time (Minimum) |
25 ms |
| Housing Material |
Stainless Steel |
| Housing Style |
Threaded Barrel |
| Thread Size |
M18 |
| Connection Type |
5-pin M12 Integral Quick Disconnect |
| Environmental Rating |
IP67 |
| NEMA Rating |
NEMA 4X |
| Adjustments |
Push Button, Remote Teach |
| Chemical Resistance |
Yes |
| Weight |
15 oz |
Information About M18TUP14Q
The M18TUP14Q is part of the Banner Engineering M18T Series temperature sensors, developed for proximity-based thermal detection using infrared energy emitted by objects. It supports remote temperature sensing from 0°C to 300°C while operating in ambient conditions from -20°C to +70°C. The sensor features a stainless steel M18 threaded barrel housing and an integral 5-pin M12 quick-disconnect for simplified installation. Configuration and threshold adjustment can be performed via push-button controls or remote teach functions using a PC interface.
Key Features:
-
Infrared temperature sensing: Detects emitted thermal energy without physical contact.
-
14:1 optical ratio: Supports accurate temperature measurement at defined distances.
-
Wide sensing range: Measures target temperatures from 0°C to 300°C.
-
Analog voltage output: Provides 0–10 VDC output for continuous temperature monitoring.
-
Integrated PNP alarm output: Supports discrete threshold-based signaling.
-
Stainless steel housing: Designed for durability in industrial environments.
-
Integral M12 quick-disconnect: Enables fast and secure electrical connection.
The M18TUP14Q delivers the reliability and precision required for non-contact industrial temperature sensing applications.
