Lenovo 4TB NVMe U.2 G3 x4 2.5" SSD Intel P4510 SSDPE2KX040T8L 01PE573 4XB7A10205
The Lenovo ThinkSystem Intel P4510 4TB (Part Numbers: 01PE573 / 4XB7A10205 / SSDPE2KX040T8L) is a high-performance enterprise NVMe SSD designed for read-intensive data center workloads. Built with Intel 64-layer 3D TLC NAND technology and leveraging a PCIe 3.0 x4 interface, this drive delivers exceptional throughput, low latency, and enterprise-grade reliability for modern server environments.
Optimized for Lenovo ThinkSystem platforms, the P4510 4TB model provides a balance of strong sequential speeds, high random IOPS, and long-term endurance suitable for cloud infrastructure, virtualization, analytics, and content delivery applications.
Core Performance
Performance Metrics
-
Sequential Read: Up to 3,000 MB/s
-
Sequential Write: Up to 2,900 MB/s
-
Random Read (4KB): Up to 636,500 IOPS
-
Random Write (4KB): Up to 111,500 IOPS
-
Typical Read Latency: 9–10 µs
-
Typical Write Latency: 11–13 µs
Reliability & Endurance
-
Endurance Rating: 0.85 Drive Writes Per Day (DWPD) for 5 years
-
Total Bytes Written (TBW): Approximately 6.3–6.45 PB
-
MTBF: 2,000,000 hours
-
Data Protection Features:
Designed for consistent enterprise reliability with safeguards against data corruption and unexpected power events.
Physical & Electrical Specifications
-
Form Factor: 2.5-inch U.2 (15mm Z-height)
-
Interface Protocol: NVMe over PCIe 3.0 x4
-
Idle Power Consumption: ~5W
-
Active Write Power: Up to 20.5W–21.5W
-
Security: 256-bit AES Hardware Encryption
-
TCG Opal 2.0: Supported on select variants
Related Part Numbers
-
SSDPE2KX040T8L
-
01PE573
-
4XB7A10205
The Lenovo ThinkSystem Intel P4510 4TB NVMe SSD delivers enterprise-class performance, low latency, and strong endurance, making it an excellent solution for high-throughput, read-optimized data center storage deployments.
