Description
The Schneider Electric KHB36150 is a molded case circuit breaker designed to provide high-interrupting overcurrent protection in three-phase electrical distribution systems. Rated at 150 amps and 600 volts, it is suitable for demanding industrial and commercial power applications. This I-Line style plug-in breaker supports reliable circuit protection where secure bolt-tightened installation is required.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Schneider Electric |
| Category |
Circuit Breaker |
| Part Number |
KHB36150 |
| Subcategory |
Molded Case Circuit Breaker |
| Series |
KHB |
| Breaker Type |
Molded case, thermal-magnetic |
| Current Rating |
150 A |
| Poles |
3 |
| Phase Configuration |
Three-phase |
| Rated Voltage |
600 V AC |
| Interrupt Rating |
35 kA @ 480 V AC |
| Mounting Style |
I-Line plug-in, bolt-tightened |
| Application Use |
Industrial and commercial power distribution |
| Manufacturer Status |
Discontinued by manufacturer |
| Weight |
32.00 lbs |
Information About KHB36150
The KHB36150 is part of the Schneider Electric KHB series, which includes high-performance molded case circuit breakers engineered for robust power distribution environments. It is built with a thermal-magnetic trip unit that provides dependable protection against overloads and short-circuit faults. The breaker is compatible with I-Line panelboard systems and features a plug-in design with bolt-tightened connections for secure mounting. Although discontinued by the manufacturer, it remains widely used for maintenance and replacement in existing electrical installations.
Key Features:
- Molded Case Circuit Breaker: Provides reliable protection against overload and short-circuit conditions.
- KHB Series Design: Engineered for high-interrupting industrial power distribution applications.
- 150 Amp Current Rating: Suitable for high-load three-phase circuits.
- High Interrupting Capacity: Rated at 35 kA at 480 VAC for fault protection.
- Three-Pole Configuration: Designed for three-phase electrical systems.
- I-Line Plug-In Style: Allows efficient installation in compatible panelboards.
- Thermal-Magnetic Trip Unit: Combines overload and instantaneous short-circuit protection.
The KHB36150 delivers the reliability and precision required for high-interrupting circuit protection in industrial and commercial electrical systems.
