Overview
Intel CM8063401286400 Xeon E5-2400 v2 E5-2430 v2 6-Core 2.5GHz 80W delivers 6 cores and 12 threads with a 3.0 GHz max turbo frequency. It features 15 MB Intel Smart Cache, 7.2 GT/s QPI speed, supports 2S scalability, and FCLGA1356 sockets.
Specifications
Model Number:CM8063401286400
Brand: Intel
Alt Part Number(s):CM8063401286400
Product Type: Processor
Technical Description
Brand: Intel
Model:CM8063401286400
Number of Cores: 6
Number of Threads: 12
Clock Speed: 2.5 GHz
Max Turbo Frequency: 3.0 GHz
Intel Smart Cache: 15 MB
Intel QPI Speed: 7.2 GT/s
Number of QPI Links: 1
Instruction Set: 64-bit
Instruction Set Extensions: AVX
Embedded Options Available: Yes
Lithography: 32 nm
Scalability: 2S Only
Max TDP: 80 W
VID Voltage Range: 0.6V-1.35V
PCI Express Revision: 3.0
Max Number of PCI Express Lanes: 24
Max CPU Configuration: 2
Package Size: 45mm x 42.5mm
Sockets Supported: FCLGA1356
*
