[shortdesc]Wi-Fi 6E, tri-radio, 2x2 MIMO, internal antennas, dual 2.5GbE, US model[shortdesc]

[properties]

Brand	HPE Aruba Networking
Model	AP-635 (US)
SKU	R7J28A
Product Type	Campus Access Point
Series	630 Series Campus Access Points
Wireless Standard	Tri-radio 2x2:2 802.11ax Wi-Fi 6E
Antenna Type	Internal Antennas
Form Factor	Indoor
Port Count	Two Ethernet wired network ports
Interface	RJ-45, USB 2.0 Type A, DC power interface
PoE Support	802.3at/bt PoE, class 4 or higher

[/properties]

[specifications]

Access Point Type	Indoor, tri radio, 2.4 GHz, 5 GHz and 6 GHz concurrent 802.11ax 2x2 MIMO
Maximum Data Rate	3.9 Gbps aggregate peak
2.4 GHz Radio	Up to 287 Mbps peak data rate
5 GHz Radio	Up to 1.2 Gbps with 2SS HE80 802.11ax client devices
6 GHz Radio	Up to 2.4 Gbps with 2SS HE160 802.11ax client devices
MIMO	Downlink multiuser MIMO supported on all radios but disabled by default
Client Capacity	Up to 512 associated client devices per radio
BSSID Support	Up to 16 BSSIDs per radio (limited to 8 for the 6 GHz radio when using version 8 software)
Supported Bands	2.400 to 2.4835 GHz, 5.150 to 5.895 GHz, 5.925 to 7.125 GHz
Radio Technologies	802.11b DSSS, 802.11a/g/n/ac OFDM, 802.11ax OFDMA
High Efficiency Support	HE20/40/80/160
Antenna Gain	4.6 dBi in 2.4 GHz, 7.0 dBi in 5 GHz, 6.3 dBi in 6 GHz
Ethernet Ports	Two RJ-45 ports with 100/1000/2500BASE-T auto-sensing link speed
Ethernet Standards	NBase-T, 802.3bz, 802.3az Energy Efficient Ethernet
Link Aggregation	LACP support between both network ports
DC Power Interface	12 Vdc nominal, +/− 5%, 2.1 mm/5.5 mm center-positive circular plug
USB Interface	USB 2.0 Type A host interface, up to 1A/5W
IoT Radio	Bluetooth Low Energy BLE5.0 and Zigbee 802.15.4 radio
GNSS Receiver	GNSS L1 receiver supporting GPS, Galileo, GLONASS, and BeiDou signal
Security Features	WPA3, Enhanced Open, WPA2-MPSK, built-in Trusted Platform Module
Power Sources	Direct DC power and Power over Ethernet on port E0 and/or E1
Maximum Power Consumption	20.7W/26.4W DC powered, 23.8W/29.4W PoE powered
Idle Power Consumption	8.7W/14.2W DC or 11.7W/17.2W PoE
Deep-Sleep Power Consumption	1.1W DC or 1.9W PoE
Operating Humidity	5% to 95% relative humidity

[/specifications]

[accesories]

Included	Mounting bracket preinstalled on the back of the access point
Optional Mounting Kit	Mount kits sold separately
Optional Power Supply	Power sources sold separately

[/accesories]

Tri-Radio Wi-Fi 6E for High-Density Campus Networks

The HPE Aruba Networking R7J28A AP-635 is a US internal antenna campus access point designed for enterprise Wi-Fi 6E deployments. It uses three dedicated radios across 2.4 GHz, 5 GHz, and 6 GHz bands to expand wireless capacity, support wider channels, and reduce interference for modern client and IoT environments.

Key Benefits and Features

• Tri-radio 802.11ax design with concurrent 2.4 GHz, 5 GHz, and 6 GHz operation.
• Delivers up to 3.9 Gbps maximum aggregate data rate across supported bands.
• Supports 2x2 MIMO for efficient wireless performance across all three radios.
• Dual HPE Smart Rate Ethernet ports support 100/1000/2500BASE-T connectivity.
• Integrated Bluetooth 5.0 and Zigbee radio supports IoT and location use cases.

Ideal Use Cases

• Enterprise campus WLAN upgrades requiring Wi-Fi 6E capacity.
• High-density offices using video, cloud apps, and many client devices.
• Indoor deployments needing internal antennas and ceiling-oriented coverage.
• Networks requiring dual Ethernet ports for redundancy and added capacity.

Technical Specifications

• SKU: R7J28A
• Model: HPE Aruba Networking AP-635 (US)
• Product Type: Campus access point
• Wi-Fi Standard: 802.11ax Wi-Fi 6E
• Radio Design: Indoor tri-radio, 2.4 GHz, 5 GHz, and 6 GHz concurrent operation
• MIMO: 2x2 MIMO
• Maximum Aggregate Data Rate: 3.9 Gbps
• Antenna Type: Internal antennas
• Ethernet Ports: Two RJ-45 ports with 100/1000/2500BASE-T auto-sensing speed
• Power Support: Direct DC power and PoE on port E0 and/or E1

Deploy HPE Aruba Wi-Fi 6E Capacity with Confidence

Choose the HPE Aruba Networking R7J28A AP-635 for enterprise campus environments that need tri-band wireless capacity, Wi-Fi 6E performance, and flexible wired uplink options in a compact indoor access point.
