HPE 1U Short Rack Rail Kit ProLiant Server (764660-001 / 764654-001) 764671-001
The HPE 1U Short Friction Rail Kit is a compact, tool-less rack mounting solution designed for short-depth HPE ProLiant servers. These rails provide a stable and cost-effective mounting option using a friction-based “stab-in” design, making them ideal for space-constrained rack environments.
Related Part Numbers
764660-001, 764654-001, 764671-001, 790563-001, 775612-B21
Part Number Overview
All listed part numbers correspond to the same 1U Short Friction Rail Kit, with variations representing option kits, spare parts, or internal sub-assemblies:
-
775612-B21 – Primary option kit
-
790563-001 / 764654-001 – Common spare kit numbers
-
764671-001 – Sub-assembly or replacement rail set
-
764660-001 – Individual rail components
Core Specifications
-
Type: 1U Friction Rail Kit (non-sliding, stab-in)
-
Rail Adjustability Range: 558.8 mm to 866.1 mm (22.0" to 34.1")
-
Minimum Rail Length: 609.6 mm (24.0")
-
Rack Compatibility: Standard 19-inch racks (square-hole, round-hole, threaded)
-
Weight Capacity: Up to 30 kg (66 lbs)
-
Installation: Tool-less design for quick deployment
Key Features
-
Friction Mount Design:
Simple and reliable mounting without ball bearings; server slides into place but does not extend outward
-
Tool-less Installation:
Fast setup with snap-in mounting for reduced deployment time
-
Compact Depth Support:
Optimized for shallow-depth racks and short chassis servers
-
Secure Fit:
Designed specifically for HPE ProLiant server chassis mounting points
Server Compatibility
These rails are designed for 1U short-depth HPE ProLiant servers, including:
ProLiant DL (Rack) Series
- DL20 Gen9 / Gen10 / Gen10 Plus
- DL120 Gen9
- DL180 Gen9
- DL320e Gen8 / Gen8 v2
Rack & System Compatibility Notes
-
Rack Standard:
Compatible with most EIA-310 compliant 19-inch 4-post racks
-
Server-Specific Fit:
While rack mounting is universal, the rail interface is proprietary to HPE ProLiant systems and typically not compatible with other brands
-
Friction Rail Limitation:
These rails do not support in-rack serviceability (no sliding extension). For maintenance access, a ball-bearing rail kit is recommended
Summary
The HPE 1U Short Friction Rail Kit is a reliable and efficient mounting solution for compact ProLiant servers. With broad rack compatibility, tool-less installation, and support for shallow-depth environments, it is ideal for data centers and edge deployments where space optimization and simplicity are critical.
