Description
The Omron H8PS-16BF Cam Positioner is a 16-output programmable positioning controller designed for precise synchronization of machine operations with rotary motion. Operating on a 24 VDC supply, it provides accurate timing and control with an easy-to-read 3-digit LCD display. This compact, surface-mount unit delivers reliable cam control in packaging, labeling, and automated production systems.
Technical Specifications
| Condition |
New/Never Used Surplus |
| Brand |
Omron |
| Category |
Industrial Automation and Controls |
| Part Number |
H8PS-16BF |
| Subcategory |
Cam Positioners |
| Alternate Part Number |
H8PS16BF |
| Series |
H8PS Series |
| Type |
Absolute Cam Positioner |
| Mounting Type |
Surface Mount |
| Output Type |
NPN |
| Number of Outputs |
16 |
| Display Type |
3-Digit LCD Display |
| Supply Voltage |
24 VDC |
| Power Consumption |
Approx. 10 W (typical for H8PS series) |
| Termination Style |
Screw Terminals |
| Control Function |
Programmable cam position and timing output |
| Input Type |
Encoder / Position Feedback (depending on configuration) |
| Enclosure Color |
Light Gray |
| Operating Temperature Range |
0°C to +55°C |
| Storage Temperature Range |
-20°C to +65°C |
| Protection Rating |
IP20 (panel-mounted applications) |
| Compliance Standards |
CE, UL, cUL Listed |
| Weight |
Approx. 0.35 kg (0.77 lb) |
Information About H8PS-16BF
The H8PS-16BF is part of Omron’s H8PS Series of cam positioners, built to simplify rotary position control in industrial automation environments. It operates on a 24 VDC power supply and features NPN transistor outputs, providing precise and responsive output signals based on encoder position feedback. The front-facing 3-digit LCD display enables easy configuration and monitoring of cam settings and angles. Designed for long-term reliability, this absolute-type positioner ensures stable, repeatable performance for motor-driven machinery and high-speed control applications.
Key Features:
- 16-Output Cam Positioner: Enables precise synchronization of machine motion and events.
- 24 VDC Power Input: Provides stable operation in control panels and automated systems.
- NPN Output Configuration: Compatible with standard transistor control circuits.
- 3-Digit LCD Display: Simplifies setup, monitoring, and adjustment of cam timing.
- Absolute Type Control: Maintains exact position data even after power cycling.
- Compact Mounting Design: Surface-mount configuration saves space in control panels.
- Screw Terminal Connections: Ensures secure and reliable wiring for industrial environments.
- Omron H8PS Series Reliability: Proven precision for high-speed and repetitive operations.
The H8PS-16BF delivers the reliability and precision required for rotary motion control, cam timing, and machine synchronization in automated production lines.
