The Gigabyte R283-Z96-ADJ1 is a high-performance 2U rack server variant of the R283-Z96 series, specifically configured to support ultra-high TDP processors (up to 500W) using an optional enhanced heatsink. It is built on the AMD EPYC™ 9005/9004 (Socket SP5) platform, designed for demanding networking, cloud-native, and general-purpose workloads.
Specifications
Model Number: R283-Z96-ADJ1
Brand: Gigabyte
Alt Part Number(s): R283-Z96-ADJ1
Product Type: Server
Technical Description
Brand: Gigabyte
Model Number: R283-Z96-ADJ1
Processor Type: AMD EPYC 9004 and 9005 Series
Processor Core: 192-Core/ 384-Thread
Processor Power: Up to ~400 W
Processor Socket: 2 × LGA 6096 (AMD SP5)
Motherboard: MSP3‑Z96
Chipset: System‑on‑Chip
Graphics Controller: ASPEED AST2600
Networking: 2 × 1 GbE RJ‑45 (via Intel I350‑AM2)
RAID Levels: 0, 1, 5, 10
Number of Drive Bays: 24 × 2.5″ Gen5 NVMe hot‑swap bays, 4 × 2.5″ SATA/SAS‑4 hot‑swap bays
Expansion Slots: 1 × FHHL PCIe ×16 slot, 1 × OCP NIC 3.0 ×16 slot
Memory Supported: 6TB
Memory Technology: DDR5 RDIMM
Memory Slots: 24 x DIMM slots
Memory Channels: 12-Channels
Cooling: 4 Fans
Power Supply: 1+1 redundant 2000 W 80 PLUS Titanium
Form Factor: 2U Rackmount
